Installation Pipe System
TITANUS MICRO·SENS
®
160
06/13
During installation, ensure that the correct connections are made (see dia-
gram):
▪ Connect the air sampling pipe system to C.
▪ Connect device to A or B and the com-pressed/pressed air to the re-
maining connection.
Connections
