Technical Data
TITANUS MICRO·SENS
®
56
06/13
Protection classification (EN 60 529)
without air return
with pipe piece 100 mm/pipe bend
with air return
IP 20
IP 42
IP 54
material plastic (ABS)
colour papyrus white, RAL 9018
TITANUS MICRO·SENS
®
deep freeze variety
– 20° to +60°C
– 40° to +60°C
not condensed max. 95 % rf (without dew)
Type of construction axial
service life of fan (12 V) 60.000 h at 24° C
Operation
Fire alarm
Action alarm
Fault
Smoke level display
Alarm location display
green operating display
red alarm display
red alarm display (optional)
yellow collective fault
yellow smoke level display 1 to 10
(10 segments) (optional)
5 red displays (optional)
Infrared interface IR
Transmitter/ Receiver
Device connection Clips for
0.5 – 2.5 mm²-wires
Cable pair twisted,
Cable feeds
device base
Device base floor
8 x M 20
2 x M 25
4 x M 25
conical
pipe plug-in connections
1 x for aspiration pipe
∅ 25 mm and
1x air return
∅ 25 mm
Detection unit
DM-TM-10 0.1 to 2.0 % light obscuration/m
DM-TM-50 0.5 to 2.0 % light obscuration/m
Protection classification
Housing
Temperature range
Humidit
y
Fan
Displays on device
Infrared interface
Connections
Reaction sensitivit
y
