Service Manual FB 7100 Programming
4 - 44 January, 2005
Example
The vending machine is to run Monday to Friday from 07:00 till 22:00. The
remaining time of the week and during the weekend the machine is set to
energy saving. Three periods have to be set as follows:
Non example 1
Non example 2
Note If a selection button is activated during an energy saving period, the
machine leaves the energy saving mode and returns to vend mode. As soon
as the temperature in the water tank has reached the ‘nominal temperature’,
the selected drink is dispensed.
When the selection buttons have been left untouched for more than 10
minutes after the last drinks dispensing, and an energy saving period is still
in force, the machine returns to the energy saving mode.
Period 1
Set start day ALL=7 Set start time 22:00
Set end day ALL=7 Set end time 23:59
Result: The machine is ‘shut down’ from Midnight 00:00 till 07:00 in the morning
the same day.
Period 2
Set start day ALL=7 Set start time 00:00
Set end day ALL=7 Set end time 07:00
Result: The machine is ‘shut down’ every day from 22:00 till Midnight the same
day.
Period 3
Set start day Fr=4 Set start time 22:00
Set end day Su=6 Set end time 23:59
Result: The machine is shut down from Friday evening at 22:00 till Sunday
evening at 23:59.
Period 1
Set start day Mo=0 Set start time 22:00
Set end day Fr=4 Set end time 07:00
Result: The machine will be ‘shut down’ Monday at 22:00 till Friday at 07:00
which was not the intention.
Period 1
Set start day All=7 Set start time 22:00
Set end day All=7 Set end time 07:00
Result: The machine is not ‘shut down’ as the end time must not be earlier than
the start time for the same ‘day’ or ‘ALL’.
