To enter Multiple Tests (Chaining)
The Media button is used when entering more
than one test. To chain one code to
another, perform the following:
1. Enter the desired code for the first test.
2. Press the MEDIA button, then enter the
additional code(s) for additional tests.
To exit from Multiple Tests
Multiple tests can be switched off by two
methods.
1. Enter the codes in the reverse sequence
from the way they were initially entered,
pressing the EXIT button after each code.
2. Press and hold the DOT (.) button while
pressing the EXIT button. This will clear all
of the codes that were entered.
Special Tests
The following tables give special diagnostic
tests that are used to enable or disable
features or to change the operating
parameters of the printer. To enter a Special
Test, the printer must first be in the diagnostic
mode
Each special test has a value that is stored in
non-volatile memory (NVM). If there is a
default value, it is found in the Value column.
NVM values may be changed by entering the
Special Test mode, pressing the ENTER
button, and then using the PREVIOUS and
NEXT arrow keys to select the desired NVM
value. To enter the selected value, press the
ENTER button again. To exit the test, press
the EXIT button.
NOTE: If there is a reference to a procedure,
the procedure must be followed in order to
perform the test correctly.
Code
[0211]
Description
Language ROM Test
0= Both Language
ROMs are defective.
1 = Primary Language
ROM is ok
2 = Secondary
Language ROM is ok
3 = Both Language
ROMs are ok
Value
Code
[0261]
[02621
[0263]
[0300]
[0360]
Description
Country Configuration
0= 115 volts
1 =240 volts (refer to
Note 1.)
2 = 220 volts
Media Width Detect
0 = 8830 DDS sizes
1 = Finesse 1.0 sizes
2 = FX sizes
5 = All sizes
Billing Meter Count
This code is used to select
the billing in meters or
inches.
0= inch
1 = metric (decimeter)
Jump 0. Restarts the lOT.
NVM Reset to Default.
Entering the number 1 or 3
resets all the NVM values
to the default values.
Entering the number 2
allows the electronic billing
to be reset to any desired
value.
1 = NACO NVM Default
2 = Billing
3= EO NVM Defaults
Value
NACO
0
EC
1
Diagnostics
1/98
6-6
8830
