Envelope Specifications
Standard Envelopes - Bypass Tray only
Refer to Table 11 and Table 12 for the envelope sizes that can be fed from the bypass tray.
NOTE: All envelope sizes quoted are with the flap closed.
Envelopes must be loaded face down in the bypass tray.
Refold of the flap is likely, if this occurs the specification is 2.5 mm up to a maximum of 4 mm
from the original fold of the envelope.
Acceptable flap types:
• Diamond / Banker
•Wallet
Weight:
• Lightweight
• Medium weight
Acceptable sealing:
• Gummed
• Press and seal
Exclusions:
• Side seam construction
• Self adhesive with release strips.
• Any type of clasp device
• Any type of window
Bent corners
(dog-ears)*
No bent corners One bent corner up to 75 mm. (3 inch) diago-
nal length
One or more bent corner exceeding 75 mm. (3
inch) diagonal length.
* Dog ears must be flattened to within
6 mm (0.25 inch) height before plac
-
ing in the input device.
Computer fan
fold sheets
- Perforated tractor feed edges cleanly
removed.
Perforated tractor feed edges not removed. -
Table 9 Input document condition definitions
Defect Acceptable Condition 1B Marginal Condition II Unacceptable Condition III Notes
Table 10 Degraded performance paper list
Media Weight (gsm) Size
Undesirable performance
characteristics
40# Starbrite 59 gsm Letter Stiffness is too low(<50 mgf)
Buckles and jams in the
media path.
Nisshinbo, SER 60 75 gsm A4 Stiffness is too low (<50mgf)
Buckles and jams in the
media path. Hi static cling
sheet to sheet results in mul
-
tipacks.
Xerox OPB Phaser
860
148 gsm Letter, A4 Sticks tenaciously to ure-
thane transfix roller surface.
Never-Tear 154 gsm Letter Hi static cling sheet resulting
in multi packs
Nisshinbo SET 130 155 gsm A4 Hi static cling sheet to sheet
resulting in multipacks.
Crown Vintage,
Curtis BrightWater
100# cover
270 gsm Letter Hi weight and stiffness
(4809mgf)
White Stripe trans-
parencies
any Letter, A4 May cause paper jams at the
imaging drum.
Table 11 European envelope sizes
ID Size Feed orientation
DL 110 x 220 mm (4.33 x 8.66 inch) SEF, Flap closed, Flap outboard (front)
or leading
C5 162 x 229 mm (6.38 x 9.02 inch) SEF, Flap closed, Flap outboard (front)
or leading
C4 229 x 324 mm (9.02 x 12.75
inch)
SEF, Flap closed, Flap outboard (front)
or leading
Table 12 American envelope sizes
ID Size Feed orientation
10# 104.8 x 241.3 mm (4.13 x 9.5
inch)
SEF, Flap closed, Flap outboard
(front)
6 x 9 152.4 x 228.6 mm (6 x 9 inch) SEF, Flap closed, Flap outboard
(front) or leading
9 x 12 228.6 x 304.8 mm (9 x 12 inch) SEF, Flap closed, Flap outboard
(front) or leading
