Xerox ColorQube 9301 Service Manual

February 2013
6-70
ColorQube® 9303 Family
GP 20
General Procedures/Information
Table 8 Input document categories definitions
Category Material Image Type
Group I. Common usage input. 80 gsm (20lb.) to 120gsm (32lb.) or equivalent weight range (rag bond
offset and ledger paper). This group includes 4040 paper.
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen.
Group II. Heavy weight common usage
input.
121gsm (32.1lb.) to 200gsm (110lb.) index or equivalent weight range
(rag bond and ledger paper).
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen.
Group III. Light weight common usage
input.
60gsm (16lb) to 79gsm (19.9lb.) bond or equivalent weight range (rag
bond, offset, mimo / duplicator, and NCR paper).
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen.
Group IV. Common surface finished paper. 60gsm (16lb) to 200gsm (110lb.) index or equivalent (Bristol text, maga-
zine, cover, vellum, safety paper)
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen.
Group V. Uncommon and other input. 80 gsm (20lb.) to 200gsm (110lb.) or equivalent weight: plastic laminated
paper: metallic cover stock: tag stock: plastic transparencies: Telecopier
paper: label stock: silver photographic paper: Electrofax paper (ZnO)
race-erase: paste ups with loose edges type 1, 2 & 3: XE approved
punched or perforated stock: Continuous computer forms.
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen. Liquid developed
electrostatic image.
Group VI. Light weight input. 49gsm (13lb.) to 59gsm 15.9lb.) bond or equivalent weight range (rag
bond, ledger mimeo or GSE papers).
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen.
Group VII.
34gsm (9lb) to 48gsm (12.9lb) bond or equivalent weight range (rag
bond, ledger mimeo or GSE papers).
Impact typewriter, offset image, Xerographic image, gravure image, Letter-
press image, pencil 2H or harder, ballpoint pen, ink pen.
Table 9 Input document condition definitions
Defect Acceptable Condition 1B Marginal Condition II Unacceptable Condition III Notes
Holes. Maximum of three cleanly punched
holes up to 6 mm. (0.25 inch) diameter.
Four to nine cleanly punched holes. Rough or torn holes. -
Staples. Cleanly removed staples. Poorly removed staples resulting in dog-
ears*.
Staples not removed. -
Edge defects. None. Any cut or tear near a corner less than 3 mm.
(0.125 inch) in length.
Any cut or tear not at a corner or greater than 3
mm. (0.125 inch) in length,
-
Folds* (in the
feed direction).
Two letter folds less than 1.5 mm.
(0.062 inch) high.
Two letter folds less than 3 mm. (0.125 inch)
high.
Any fold greater than 3 mm. (0.125 inch) high. * Folds must be flattened to within 6
mm (0.25 inch) height before placing
in the input device.
Folds* (across
the feed direc
-
tion)
None. One fold not to exceed 3 mm. (0.125 inch)
high.
Any fold greater than 3 mm. (0.125 inch) high. * Folds must be flattened to within 6
mm (0.25 inch) height before placing
in the input device.
Curl (measured
from a flat sur
-
face).
None. In-ream or inherent curl up to 13 mm. (0.5
inch) maximum.
- Curl greater than 13 mm.
Wrinkle. None. Multiple moderate wrinkles, up to 38 mm. (1.5
inch) long in any direction, 3 mm. (0.125 inch)
in height.
Severe wrinkles greater than 38 mm. (1.5 inch)
long in any direction, greater than 3 mm. (0.125
inch) in height
-
Foreign material
on the surface.
None. Hole reinforcement, correction fluid or dry
glue no greater than 13 square millimeters.
(0.02 square inch) per correction.
Correction tape major paste-up or correction
fluid greater than 13 square millimeters. (0.02
square inch) per correction.
-
