Xerox ColorQube 9301

February 2013
6-145
ColorQube® 9303 Family
dC131
General Procedures/Information
490-066 PQM ISM Status ISM Status: PQMs status
tracking for the ISM feature.
0 = Optimal, PQM has calcu-
lated that ISM-Purge is NOT
NEEDED
1 = NonOptimal, PQM has
calculated that ISM-Purge is
NEEDED
3= Manually disabled:ISM fea-
ture is Off - default value
4 = Manually Enabled: ISM
feature has been enabled by a
user
Range = 0 to 4 3
490-067 PQM ISM Calc
Threshold
ISM Calc Cycles: Indicates
how many of the most recent
Ink Usage Cycles (up to 8)
should be used in the calcula
-
tion.
Range = 0 to 65,535 40
490-068 PQM Calc Cycles ISM Calc Threshold: It indi-
cates the minimum amount of
ink that must be used over the
calculated period to avoid
purging at night.
Range = 0 to 8 1
492-001 Image on drum Image on drum Range = 0 to 1 0
492-002 DM can scrape off
DM can scrape off image Range = 0 to 1 0
492-003 Drum image is 2
pitch
Drum image is 2 pitch Range = 0 to 1 0
492-004 Position of dirty
drum image
Drum dirty start position Range = 0 to 65,535 0
492-005 Size of drum
image X
Size of drum image Range = 0 to 65,535 0
492-006 Size of drum
image Y
Size of drum image Range = 0 to 65,535 0
492-007 Position of drum
Cross process drum offset
position
Range = -32,768 to
32,767
0
492-008 Drum runout cal
#01
Calibration values of the drum
y-run out
Range = -32,768 to
32,767
0
492-009 Drum runout cal
#02
Calibration values of the drum
y-run out
Range = -32,768 to
32,767
0
492-010 Drum runout cal
#03
Calibration values of the drum
y-run out
Range = -32,768 to
32,767
0
492-011 Drum runout cal
#04
Calibration values of the drum
y-run out
Range = -32,768 to
32,767
0
Table 6 IOT NVM (IME) ID Range 489 to 499-xxx
NVM ID NVM Name NVM Description Settings Default
492-012 Drum runout cal
#05
Calibration values of the drum
y-run out
Range = -32,768 to
32,767
0
492-013 Drum runout cal
#06
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-014 Drum runout cal
#07
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-015 Drum runout cal
#08
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-016 Drum runout cal
#09
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-017 Drum runout cal
#10
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-018 Drum runout cal
#11
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-019 Drum runout cal
#12
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-020 Drum runout cal
#13
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-021 Drum runout cal
#14
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-022 Drum runout cal
#15
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-023 Drum runout cal
#16
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-024 Drum runout cal
#17
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-025 Drum runout cal
#18
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-026 Drum runout cal
#19
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-027 Drum runout cal
#20
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-028 Drum runout cal
#21
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-029 Drum runout cal
#22
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-030 Drum runout cal
#23
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-031 Drum runout cal
#24
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-032 Drum runout cal
#25
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
492-033 Drum runout cal
#26
Calibration values of the drum
y-runout
Range = -32,768 to
32,767
0
Table 6 IOT NVM (IME) ID Range 489 to 499-xxx
NVM ID NVM Name NVM Description Settings Default
