Xerox ColorQube 9301 Service Manual

February 2013
6-144
ColorQube® 9303 Family
dC131
General Procedures/Information
490-048 A correction offset
value applied to Y
stitch rear mea
-
surements for
stitch interface 2.
Stitch Measure Offset Y2 Rear Range = -1000 to
1000
0
490-049 A correction offset
value applied to Y
stitch rear mea
-
surements for
stitch interface 3.
Stitch Measure Offset Y3 Rear Range = -1000 to
1000
0
490-050 TMP:H1Fix Jets
Purge Needed
TMP = too many purges fea-
ture
TMP: count of semi-consecui-
tive nights in which head 1
sees purge needed to fix jets.
Range = 0 to 255 0
490-051 TMP:H2Fix Jets
Purge Needed
TMP: count of semi-consecui-
tive nights in which head 2
sees purge needed to fix jets.
Range = 0 to 255 0
490-052 TMP:H3Fix Jets
Purge Needed
TMP: count of semi-consecui-
tive nights in which head 3
sees purge needed to fix jets.
Range = 0 to 255 0
490-053 TMP:H4Fix Jets
Purge Needed
TMP: count of semi-consecui-
tive nights in which head 4
sees purge needed to fix jets.
Range = 0 to 255 0
490-054 TMP:H1Fix Jets
Prg NOT Needed
TMP: count of semi-consecui-
tive nights in which head 1
sees purge NOT needed to fix
jets.
Range = 0 to 255 0
490-055 TMP:H2Fix Jets
Prg NOT Needed
TMP: count of semi-consecui-
tive nights in which head 2
sees purge NOT needed to fix
jets.
Range = 0 to 255 0
490-056 TMP:H3Fix Jets
Prg NOT Needed
TMP: count of semi-consecui-
tive nights in which head 3
sees purge NOT needed to fix
jets.
Range = 0 to 255 0
490-057 TMP:H4Fix Jets
Prg NOT Needed
TMP: count of semi-consecui-
tive nights in which head 4
sees purge NOT needed to fix
jets.
Range = 0 to 255 0
Table 6 IOT NVM (IME) ID Range 489 to 499-xxx
NVM ID NVM Name NVM Description Settings Default
490-058 TMP:Max Fix Jets
Purge Needed
TMP: A threshold of purge
maintenance sessions that
had purges to correct bad jets.
If this threshold is exceeded a
Head x Too Many Purges infor
-
mational fault is raised and the
heads jet fix purging is
blocked.
Range = 0 to 255 16
490-059 TMP:Max Fix Jets
Prg NOT Needed
TMP: When the number of
purge maintenance sessions
which requires no purges to fix
bad jets exceeds this value the
Head x Too Many Purges Dev
-
Fault is lowered
Range = 0 to 255 2
490-060 Unif-CLD Base-
line Status
CLD = CloseLoopDrift = a new
way to achieve uniformity via
IOD. CLD baseline (via IOD) is
a new calibration required by
uniformity (CLDAdjust). This is
PQM status for CLD baseline.
Range = 0 to 255 0
490-061 Unif-CLD Base-
line Failure
PQM consecutive failure count
for CLD baseline
Range = 0 to 4 1
490-062 Unif-CLD Base-
line Last Success
What is the youngest heads
time at temp when CLD base
-
line last succeeded
Range = 0 to
4,294,967,295
0
490-063 Wait GelMaint
until CU-PC
Min CU print count before
PQM begins running automatic
CU Gel Maintenance at night.
Range = 0 to
4,294,967,295
25,000
490-064 Override Unifor-
mity Algorithm
Switch to go back to old unifor-
mity algorithm vs new closed
loop drift algorithm.
0 = New CLD unifor-
mity
1 = Old uniformity
Range = 0 to 225
0
490-065 Delta CU-PC
between Gel
-
Maint
Min CU print count between
automatic CU Gel mainte
-
nances at night
Range = 0 to
4,294,967,295
5,000
Table 6 IOT NVM (IME) ID Range 489 to 499-xxx
NVM ID NVM Name NVM Description Settings Default
