February 2013
6-147
ColorQube® 9303 Family
dC131
General Procedures/Information
498-005 Pest Fault Over-
ride Parameter 4
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-006 Pest Fault Over-
ride Parameter 5
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-007 Pest Fault Over-
ride Parameter 6
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-008 Pest Fault Over-
ride Parameter 7
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-009 Pest Fault Over-
ride Parameter 8
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-010 Pest Fault Over-
ride Parameter 9
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-011 Pest Fault Over-
ride Parameter 10
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-012 Pest Fault Over-
ride Parameter 11
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-013 Pest Fault Over-
ride Parameter 12
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-014 Pest Fault Over-
ride Parameter 13
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-015 Pest Fault Over-
ride Parameter 14
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-016 Pest Fault Over-
ride Parameter 15
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-017 Pest Fault Over-
ride Parameter 16
Space reserved for PEST fault
override
Range = - 32,768 to
32,767
- 1
498-018 Suppress PEST
Fault Overrides
Space reserved for PEST fault
override
0 = Do not suppress
warning
1 = Suppress warn-
ings
Range = 0 to 1
0
499-001 LVDS frame for-
mat
Set LVDS frame format Range = 0 to 2 2
499-002 Air accumulator is
installed
Ink purge air accumulator is
installed
1 = installed
Range = 0 to 1
1
499-003 Lower carriage
wiper engage
Lower printhead carriage when
engaging wiper
Range = - 600 to 0 0
499-004 Upper carriage
wiper engage
Upper printhead carriage when
engaging wiper
Range = - 400 to 0 0
499-005 Fast decay strip-
per is installed
Fast decay stripper is installed Range = 0 to 1 1
499-006 Spring damper
stripper installed
Spring damper stripper mod is
installed
Range = 0 to 1 0
499-007 Head adjust
motor type
Head adjust motor type Range = 0 to 65,535 1
Table 6 IOT NVM (IME) ID Range 489 to 499-xxx
NVM ID NVM Name NVM Description Settings Default
499-008 Ink SKU motor
type
Ink SKU motor type Range = 0 to 65,535 1
499-009 Lp4c paper path
motor2 installed
Lp4c paper path motor 2 is
installed
Range = 0 to 1 0
499-010 Lp4c paper path
motor6 installed
Lp4c paper path motor 6 is
installed
Range = 0 to 1 0
499-011 Ink plate ther-
mistor type
Ink plate thermistor PT312 is
installed
Range = 0 to 1 1
499-012 Printhead car-
riage sensor post
Printhead carriage sensor
flags are on the carriage frame
Range = 0 to 1 1
499-013 Finisher type Type of finisher installed Range = 0 to 65,535 255
499-014 PP1 Rev Melt
Plate installed
The PP1 revision melt plate is
installed
1 = installed
Range = 0 to 1
0
499-015 PP1 Rev Ink
Loader installed
The PP1 revision ink loader is
installed
1 = installed
Range = 0 to 1
0
499-016 MSI HW Revision Hardware Version of the MSI Range = 0 to 1 1
499-017 Upper Stripper
Guide Installed
Upper Stripper Guide is
installed
Range = 0 to 1 1
499-018 Low Friction Strip-
per Installed
Low Friction Stripper Drive is
installed
Range = 0 to 1 1
499-019 Finisher Input
Skew Installed
Finisher Input Skew Upgrade
has been installed
Range = 0 to 1 0
499-020 HW Config Spare
5
Hardware Config Spare value
5
Range = -
2,147,483,648 to
2,147,483,647
0
499-021 HW Config Spare
6
Hardware Config Spare value
6
Range = -
2,147,483,648 to
2,147,483,647
0
499-022 HW Config Spare
7
Hardware Config Spare value
7
Range = -
2,147,483,648 to
2,147,483,647
0
499-023 HW Config Spare
8
Hardware Config Spare value
8
Range = -
2,147,483,648 to
2,147,483,647
0
499-024 Upgrade Sensor
12 Location
Sensor 12 location with Idler
Upgrade
Range = 25,440 to
26,740
26,240
499-025 Upgrade Sensor
15 Location
Sensor 15 location with Idler
Upgrade
Range = 43,481 to
44,781
44,281
499-026 Manufacturing
Use Only 1
Manufacturing Use Only 1 Range = 0 to 255 0
499-027 Manufacturing
Mode
Indicates the system is in spe-
cial manufacturing mode used
during initial build of IME.
0 = Not in initial
manufacturing mode
1 = Initial manufac-
turing mode
Range = 0 to 1
0
Table 6 IOT NVM (IME) ID Range 489 to 499-xxx
NVM ID NVM Name NVM Description Settings Default
