Xerox ColorQube 9301 - Page 1440

February 2013
6-148
ColorQube® 9303 Family
dC131
General Procedures/Information
Table 7 CCS NVM ID 600-xxx
NVM ID NVM Name NVM Description Settings Default
600-001 Compression
Mode
Compression Mode Range = 0 to 1 0
600-002 Reserved Blocks Reserved blocks Range = 0 to 5 0
600-003 Megs of Memory Megs of memory Range = 0 to 65,535 16
600-004 EPC memory low
percent
EPC memory low percent Range = 1 to 99 38
600-005 Disk Mode Disk Mode Range = 0 to 1 1
600-006 Memory Out
Bound
Memory Out Bound Range = 0 to 6 6
600-007 EPC memory full
percent
EPC memory full percent Range = 1 to 99 12
600-008 Use Partial
Blocks
Use Partial Blocks Range = 0 to 1 1
600-009 BlockSize in K Block size in K Range = 200 to 200 200
600-010 Initial Blocks initial blocks Range = 12 to 24 12
600-011 Blocks Needed Blocks Needed Range = 8 to 20 8
600-012 Frame Size Frame Size Range = 923 to 923 923
600-013 Percent of Frame
Size
Percent of frame size Range = 1 to 99 70
600-014 Making mode
when EPC full
Making mode when EPC full Range = 0 to 3 0
600-015 Ram Size Mis-
match Fault
Fault counter 19-750-00:
Video EPC Size Mismatch
Cntr
Range = 0 to 255 0
600-016 Disk Mode Mis-
match Fault
Fault counter 19-754-00:
Video Disk Mismatch Cntr
Range = 0 to 255 0
600-017 Out Memory Fault
- StrNC docFC
Fault counter 19-401-00:
Out memory fault - stress doc-
ument
Range = 0 to 255 0
600-018 Compressor
DVMA Timeout
Fault
Fault counter 19-402-00:
Fault Video DVMST Timeout
fault (Compressor DVMA time
-
out fault)
Range = 0 to 255 0
600-019 Memory on Target Amount of EPC memory Range = 0 to 65535 512
600-020 AHA End of
Record Fault
Fault counter 22-300-00:
AHA end of record fault
Range = 0 to 255 0
600-021 Disk spin up
delay time
Time before image disk
receives power (sec)
Range = 0 to 30 10
600-022 Platinum Board
Full Concurrency
Platinum board full concur-
rency
Range = 0 to 1 1
600-023 Image disk parti-
tion size
Image disk partition size Range = 0 to 30 4
600-024 Image Disk Dirty Image Disk Dirty Range = 0 to 1 0
600-025 IJO Enabled IJO Enabled Range = 0 to 1 0
600-026 Disk Dirty at
power up
Disk Dirty at power up Range = 0 to 1 0
600-027 Maximum net-
work read
attempts
Value of maximum network
read attempts
Range = 0 TO 255 3
600-028 KDrumPixelCount K Drum Pixel Count Range = 0 to
4.294.967,295
0
600-029 CDrumPixelCount C Drum Pixel Count Range = 0 to
4.294.967,295
0
600-030 MDrumPixel-
Count
M Drum Pixel Count Range = 0 to
4.294.967,295
0
600-031 YDrumPixelCount Y Drum Pixel Count Range = 0 to
4.294.967,295
0
600-032 vramLevel1RecT
hreshhold
vram Level1 Rec Threshold Range = 0 to
4.294.967,295
471859
200
600-033 vramLevel1TripTh
reshhold
vram Level 1 Trip Threshold Range = 0 to
4.294.967,295
419430
400
600-034 vramLevel2RecT
hreshhold
vram Level 2 Rec Threshold Range = 0 to
4.294.967,295
367001
600
600-035 vramLevel2TripTh
reshhold
vram Level 2 Trip Threshold Range = 0 to
4.294.967,295
314572
800
600-036 vramLevel3RecT
hreshhold
vram Level 3 Rec Threshold Range = 0 to
4.294.967,295
256901
120
600-037 vramLevel3TripTh
reshhold
vram Level 3 Trip Threshold Range = 0 to
4.294.967,295
209715
200
600-038 vramLevel4RecT
hreshhold
vram Level 4 Rec Threshold Range = 0 to
4.294.967,295
175112
192
600-039 vramLevel4TripTh
reshhold
vram Level 4 Trip Threshold Range = 0 to
4.294.967,295
140509
184
600-040 vramLevel5RecT
hreshhold
vram Level 5 Rec Threshold Range = 0 to
4.294.967,295
105906
176
600-041 vramLevel5TripTh
reshhold
vram Level 5 Trip Threshold Range = 0 to
4.294.967,295
702545
92
600-042 vramLevel6RecT
hreshhold
vram Level 6 Rec Threshold Range = 0 to
4.294.967,295
356515
84
600-043 vramLevel6TripTh
reshhold
vram Level 6 Trip Threshold Range = 0 to
4.294.967,295
104857
6
600-044 cacheAIIImag-
esToDisk
CacheAIIImagesToDisk Range = 0 to 1 0
600-045 Total Black Pixel
Count Low
Total black pixel count low Range = 0 to
4.294.967,295
0
Table 7 CCS NVM ID 600-xxx
NVM ID NVM Name NVM Description Settings Default
