Xerox ColorQube 9301 - Page 1448

February 2013
6-156
ColorQube® 9303 Family
dC131
General Procedures/Information
604-109 Not displayed No Finisher Capability Found Range = 0 to
16777215
0
604-111 Not displayed No IOT Capability Found Range = 0 to
16777215
0
604-112 MSDefaultTray-
Train
Range 0 to 2 0
604-113 MSDefaultTray-
Stack
Range 0 to 1 0
604-114 MSDefaultTrayId Range 0 to 4 0
604-115 Propose Count
No Finisher
Range 2 to 16 12
604-116 LastJobIDToRe-
cover
Last job ID to recover Range 0 to 65535 0
604-117 Not displayed Last document ID to recover -
doc to recover
Range 0 to 65535 0
604-118 LastImage-
IDToRecover
Last image ID to recover Range 0 to 65535 0
604-119 IOTCommFault-
Count
IOT Comm Fault Count Range 0 to 3 0
604-120 PrintPagesCom-
pleted
Print Pages Completed Range 0 to 65535 0
604-121 SetsCompleted Last set Completed Range 0 to 65535 0
604-122 LastService-
IDToRecover
Last service ID to recover Range 0 to 65535 0
604-123 QtyToRecover Quantity to recover Range 0 to 65535 0
604-124 Not displayed Tag matrix Range 0 to 65535 0
604-125 MSDefaultDe-
curler
Default decurler level settings 0 = Low decurler
1 = Normal decurler
2 = High decurler
Range 0 to 2
1
604-126 Not displayed Serial number Range 0 to 1 0
604-127 MSOffsetEna-
bledPolicy
Enable offset policy 0 = Off
1 = On
Range 0 to 1
0
604-128 SerNumSet Serial number set Range 0 to 1 0
604-129 MSOutOfStaple-
sPolicy
Out of staples policy setting 0 = Hold
1 = Stapling defeated
Range 0 to 1
1
604-131 ProdCfgNvm ProdCfgNvm Range 0 to 65535 0
604-132 Last sheet to
recover
Last sheet to recover Range 0 to 108 106
604-133 TotalQuanitity-
Made
Total quantity requested for the
current job
Range 0 to 65535 0
Table 10 CCS NVM ID 604-001 to 604-299
NVM ID NVM Name NVM Description Settings Default
604-134 ModuleHas-
BeenSetUp
Module has been set up Range 0 to 1 0
604-135 Not displayed Counter - Stapled31_50 Range 0 to 16777215 0
604-136 Not displayed Counter - Stapled51_100 Range 0 to 16777215 0
604-137 Propose Count
MCSS Finisher
Propose Count MCSS Finisher Range 2 to 16 12
604-138 IOT Diag Enter
TO SEC
IOT Diag Enter TO SEC Range = 0 to 1800 30
604-139 IOT Diag Exit TO
SEC
IOT Diag Exit TO SEC Range = 0 to 1800 30
604-140 IOT Diag Test
Pattern TO SEC
IOT Diag Test Pattern TO SEC Range = 0 to 1800 0
604-141 IOT Diag Device
Status TO SEC
IOT Diag Device Status TO
SEC
Range = 0 to 1800 0
604-142 IOT Diag Analog
Monitor TO SEC
IOT Diag Analog Monitor TO
SEC
Range = 0 to 1800 0
604-143 IOT Diag In Out
Manual TO SEC
IOT Diag In Out Manual TO
SEC
Range = 0 to 1800 0
604-144 IOT Diag PP Tim-
ing TO SEC
IOT Diag PP Timing TO SEC Range = 0 to 1800 0
604-145 IOT Diag MSI
Side Guide TO
SEC
IOT Diag MSI side guide TO
SEC
Range = 0 to 1800 0
604-146 IOT Diag Sys
Regi TO SEC
IOT Diag Sys Regi TO SEC Range = 0 to 1800 0
604-147 IOT Diag Reg
Setup TO SEC
IOT Diag Reg Setup TO SEC Range = 0 to 1800 0
604-148 IOT Diag Reg
Check TO SEC
IOT Diag Reg Check TO SEC Range = 0 to 1800 0
604-149 IOT Diag Reg
Sens Check TO
SEC
IOT Diag Reg Sens Check TO
SEC
Range = 0 to 1800 0
604-150 IOT ATC Sensor
Setup TO SEC
IOT ATC Sensor Setup TO
SEC
Range = 0 to 1800 0
604-151 IOT Diag Belt
Edge Learn TO
SEC
IOT Diag Belt Edge Learn TO
SEC
Range = 0 to 1800 0
604-152 IOT TRC Adjust
TO SEC
IOT TRC Adjust TO SEC Range = 0 to 1800 0
604-153 IOT Diag Tone Up
Down TO SEC
IOT Diag Tone Up Down TO
SEC
Range = 0 to 1800 0
604-154 IOT Diag No
Paper Run TO
SEC
IOT Diag No Paper Run TO
SEC
Range = 0 to 1800 0
Table 10 CCS NVM ID 604-001 to 604-299
NVM ID NVM Name NVM Description Settings Default
