Xerox ColorQube 9301 - Page 1449

February 2013
6-157
ColorQube® 9303 Family
dC131
General Procedures/Information
604-155 IOT Diag ProCon
On Off TO SEC
IOT Diag ProCon ON Off TO
SEC
Range = 0 to 1800 0
604-156 IOT Diag Binary
Cal TO SEC
IOT Diag Binary Cal TO SEC Range = 0 to 1800 0
604-157 IOT Diag Fold
Position TO SEC
IOT Diag Fold Position TO
SEC
Range = 0 to 1800 0
604-158 IOT Diag
CTRACS TO
SEC
IOT Diag CTRACS TO SEC Range = 0 to 1800 0
604-159 IOT Diag Comp
Ctrl TO SEC
IOT Diag Comp Ctrl TO SEC Range = 0 to 1800 0
604-160 CCMCannotCom-
municateWithlo-
tFC
Fault counter 03-316:
CCM Cannot Communicate
With lot FC
Range = 0 to 255 0
604-171 BookletinSnrOn-
JamFault-
CountFC
Fault counter 12-113:
Booklet in Snr On Jam Fault-
Count FC
Range = 0 to 255 0
604-172 BookletinSnrOff-
JamFault-
CountFC
Fault counter 12-114:
Booklet in Snr Off Jam Fault-
Count FC
Range = 0 to 255 0
604-174 GateSnrOnJam-
FaultCountFC
Fault counter 12-125:
Gate Snr On Jam Fault Count
FC
Range = 0 to 255 0
604-175 XportEntSnrOn-
JamFault-
CountFC
Xport Ent Snr On Jam Fault
Count FC
Range = 0 to 255 0
604-176 BufferPathSnrOn-
JamFault-
CountFC
Fault counter 12-142:
Buffer Path Snr On Jam Fault
Count FC
Range = 0 to 255 0
604-177 CompilerExitSn-
rOffJamFC
Fault counter 12-151:
Compiler Exit Snr Off Jam FC
Range = 0 to 255 0
604-178 CompilerExitSn-
rOnJamFault-
CountFC
Fault counter 12-152:
Compiler Exit Snr On Jam
Fault Count FC
Range = 0 to 255 0
604-181 TopTrayExitSn-
rOnJamFault-
CountFC
Fault counter 12-171:
Top Tray Exit Snr On Jam
Fault Count FC
Range = 0 to 255 0
604-182 TopTrayExitSn-
rOffJamFault-
CountFC
Fault counter 12-172:
Top Tray Exit Snr Off Jam
Fault Count FC
Range = 0 to 255 0
604-241 OCTOffsetFail-
CountFC
Fault counter 12-701:
OCT Offset Fail Count FC
Range = 0 to 255 0
604-271 Tray1MisfeedJam
CountFC
Fault counter 71-101:
Tray 1 Misfeed Jam Count FC
Range = 0 to 255 0
Table 10 CCS NVM ID 604-001 to 604-299
NVM ID NVM Name NVM Description Settings Default
604-275 Tray2MisfeedJam
CountFC
Fault counter 72-101:
Tray 2 Misfeed Jam Count FC
Range = 0 to 255 0
604-280 Tray3MisfeedJam
CountFC
Fault counter 73-101:
Tray 3 Misfeed Jam Count FC
Range = 0 to 255 0
604-285 Tray4MisfeedJam
CountFC
Fault counter 74-101:
Tray 4 Misfeed Jam Count FC
Range = 0 to 255 0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
604-372 DFinBufferPath-
SnrOffJam FC
Fault Counter 12-141: DFin-
BufferPathSnrOffJam FC
Range = 0 to 255 0
604-397 Not displayed TotalIOTJamsC30-
TotalIOTJamsC30
Range = 0 to
16777215
0
604-398 Not displayed AttemptedFeedsfromBypassTr
ayC39-
AttemptedFeedsfromBypassTr
ayC39
Range = 0 to
16777215
0
604-399 Not displayed ActualFeedsfromBypassTrayC
40-
ActualFeedsfromBypassTrayC
40
Range = 0 to
16777215
0
604-400 Not displayed AttemptedPaperFeedsC32-
AttemptedPaperFeedsC32
Range = 0 to
16777215
0
604-401 Not displayed ActualPaperFeedsC33-
ActualPaperFeedsC33
Range = 0 to
16777215
0
604-402 Not displayed KnownJamsinFinishingdevices
C31-
KnownJamsinFinishingdevices
C31
Range = 0 to
16777215
0
604-403 Not displayed AllsheetsfedfromTray1-
AllsheetsfedfromTray1
Range = 0 to
16777215
0
604-404 Not displayed AllsheetsfedfromTray2-
AllsheetsfedfromTray2
Range = 0 to
16777215
0
604-405 Not displayed AllsheetsfedfromTray3-
AllsheetsfedfromTray3
Range = 0 to
16777215
0
604-406 Not displayed AllsheetsfedfromTray4-
AllsheetsfedfromTray4
Range = 0 to
16777215
0
604-407 Not displayed AllsheetsfedfromBypassTray-
AllsheetsfedfromBypassTray
Range = 0 to
16777215
0
604-408 Not displayed TotalSheetsside1-
TotalSheetsside1
Range = 0 to
16777215
0
604-409 Not displayed TotalSheetsside1and2-
TotalSheetsside1and2
Range = 0 to
16777215
0
Table 10 CCS NVM ID 604-001 to 604-299
NVM ID NVM Name NVM Description Settings Default
