Xerox ColorQube 9301 - Page 1452

February 2013
6-160
ColorQube® 9303 Family
dC131
General Procedures/Information
604-472 ImeMPS11TETim
eoutFC
Fault counter for 10-113: IME
Media Path Sensor 11 TE tim
-
eout-ImeMPS11TETimeoutFC
Number of faults
Range = 0 to 255
0
604-473 ImeMPS12Sheet
TooLongFC
Fault counter for 10-125: IME
Media Path Sensor 12 sheet
too long-
ImeMPS12SheetTooLongFC
Number of faults
Range = 0 to 255
0
604-474 ImeMPS12Sheet
TooShortFC
Fault counter for 10-126: IME
Media Path Sensor 12 sheet
too short-
ImeMPS12SheetTooShortFC
Number of faults
Range = 0 to 255
0
604-475 ImeMPS12LETim
eoutFC
Fault counter for 10-127: IME
Media Path Sensor 12 LE tim
-
eout-ImeMPS12LETimeoutFC
Number of faults
Range = 0 to 255
0
604-476 ImeMPS12TETim
eoutFC
Fault counter for 10-128: IME
Media Path Sensor 12 TE tim
-
eout-ImeMPS12TETimeoutFC
Number of faults
Range = 0 to 255
0
604-477 ImeMPS15Sheet
TooLongFC
Fault counter for 10-140: IME
Media Path Sensor 15 sheet
too long-
ImeMPS15SheetTooLongFC
Number of faults
Range = 0 to 255
0
604-478 ImeMPS15Sheet
TooShortFC
Fault counter for 10-141: IME
Media Path Sensor 15 sheet
too short-
ImeMPS15SheetTooShortFC
Number of faults
Range = 0 to 255
0
604-479 ImeMPInvS15Sh
eetTooLongFC
Fault counter for 10-142: IME
Media Path Invert Sensor 15
sheet too long-
ImeMPInvS15SheetTooLongF
C
Number of faults
Range = 0 to 255
0
604-480 ImeMPInvS15Sh
eetTooShortFC
Fault counter for 10-143: IME
Media Path Invert Sensor 15
sheet too short-
ImeMPInvS15SheetTooShortF
C
Number of faults
Range = 0 to 255
0
604-481 ImeMPS15LETim
eoutFC
Fault counter for 10-144: IME
Media Path Sensor 15 LE tim
-
eout-ImeMPS15LETimeoutFC
Number of faults
Range = 0 to 255
0
604-482 ImeMPS15TETim
eoutFC
Fault counter for 10-145: IME
Media Path Sensor 15 TE tim
-
eout
Number of faults
Range = 0 to 255
0
604-483 ImeMPInvS15LE
TimeoutFC
Fault counter for 10-146: IME
Media Path Invert Sensor 15
LE timeout
Number of faults
Range = 0 to 255
0
604-484 ImeTfixLoad-
FrontForceFailFC
Fault counter for 10-500: IME
Transfix Load front force failure
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
604-485 ImeTfixLoadRear-
ForceFailFC
Fault counter for 10-505: IME
Transfix Load rear force failure
Number of faults
Range = 0 to 255
0
604-486 ImeTfix-
LoadTimingErrFC
Fault counter for 10-510: IME
Transfix Load timing error
Number of faults
Range = 0 to 255
0
604-489 ImeTfixLoadMo-
torFailFC
Fault counter for 10-525: IME
Transfix Load Home Motor dis
-
able failure
Number of faults
Range = 0 to 255
0
604-490 ImeTfixGapSet-
FailedFC
Fault counter for 10-530: IME
Transfix gap set failed
Number of faults
Range = 0 to 255
0
604-491 ImeTfixLoadCal-
FailFC
Fault counter for 10-535: IME
Transfix Load calibration fail
-
ure
Number of faults
Range = 0 to 255
0
604-492 ImeTfix-
Ta sk La te FC
Fault counter for 10-540: IME
Transfix task late
Number of faults
Range = 0 to 255
0
604-493 ImeTfixDrumInit-
PosWrongFC
Fault counter for 10-545: IME
Transfix Drum initial position
wrong
Number of faults
Range = 0 to 255
0
604-494 ImeTfixDrum-
StallFC
Fault counter for 10-550: IME
Transfix Drum stall
Number of faults
Range = 0 to 255
0
604-495 ImePostTrans-
fixMtr(M4)Over-
currFC
Fault counter for 10-555: IME
M4 over current
Number of faults
Range = 0 to 255
0
604-496 ImeTfixFron-
tOvercurrFC
Fault counter for 10-560: IME
Transfix front over current
Number of faults
Range = 0 to 255
0
604-497 ImeTfixRearOver-
currFC
Fault counter for 10-565: IME
Transfix rear over current
Number of faults
Range = 0 to 255
0
604-499 ImeAbatFanOver-
currFC
Fault counter for 42-505: IME
Abatement fan over current
Number of faults
Range = 0 to 255
0
604-500 ImeVertTransS5S
heetTooEarlyFC
Fault counter for 82-110: IME
Media Path Sensor 5 sheet too
early
Number of faults
Range = 0 to 255
0
604-501 ImeVertTransS5S
heetMisLongFC
Fault counter for 82-111: IME
Media Path Sensor 5 sheet
mismatch long
Number of faults
Range = 0 to 255
0
604-502 ImeVertTransS5S
heetMisShortFC
Fault counter for 82-112: IME
Media Path Sensor 5 sheet
mismatch short
Number of faults
Range = 0 to 255
0
604-503 ImeVertTransS5L
ETimeoutFC
Fault counter for 82-113: IME
Media Path Sensor 5 LE time
-
out
Number of faults
Range = 0 to 255
0
604-504 ImeVertTransS5T
ETimeoutFC
Fault Counter 82-114: IME
Vertical Trans Sensor 5 TE
timeout
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
