Xerox ColorQube 9301

February 2013
6-161
ColorQube® 9303 Family
dC131
General Procedures/Information
604-505 ImeConfirmS16S
heetTooEarlyFC
Fault counter for 82-125: IME
Media Path Sensor 16 sheet
too early
Number of faults
Range = 0 to 255
0
604-506 ImeConfirmS16S
heetTooLongFC
Fault counter for 82-126: IME
Media Path Sensor 16 sheet
too long
Number of faults
Range = 0 to 255
0
604-507 ImeMPS16Sheet
TooShortFC
Fault counter for 82-127: IME
Media Path Sensor 16 sheet
too short
Number of faults
Range = 0 to 255
0
604-508 ImeConfirmS16S
heetMisLongFC
Fault counter for 82-128: IME
Media Path Sensor 16 sheet
mismatch long
Number of faults
Range = 0 to 255
0
604-509 ImeConfirmS16S
heetMisShortFC
Fault counter for 82-129: IME
Media Path Sensor 16 sheet
mismatch short
Number of faults
Range = 0 to 255
0
604-510 ImeConfirmS16L
ETimeoutFC
Fault counter for 82-130: IME
Media Path Sensor 16 LE tim
-
eout
Number of faults
Range = 0 to 255
0
604-511 ImeConfirmS16T
ETimeoutFC
Fault counter for 82-131: IME
Media Path Sensor 16 TE tim
-
eout
Number of faults
Range = 0 to 255
0
604-512 ImeConfirmDuple
xS16LETimeoutF
C
Fault counter for 82-132: IME
Media Path Duplex Sensor 16
LE timeout
Number of faults
Range = 0 to 255
0
604-513 ImeDuplexEnd-
SheetTooWideFC
Fault counter for 82-140: IME
Media Path sheet too wide
Number of faults
Range = 0 to 255
0
604-514 ImeDuplexEndS1
4SheetTooEarlyF
C
Fault counter for 82-141: IME
Media Path Sensor 14 sheet
too early
Number of faults
Range = 0 to 255
0
604-515 ImeMPSheet-
TooNarrowFC
Fault counter for 82-142: IME
Media Path sheet too narrow
Number of faults
Range = 0 to 255
0
604-516 ImeDuplexEndS1
4SheetTooLongF
C
Fault counter for 82-145: IME
Media Path Sensor 14 sheet
too long
Number of faults
Range = 0 to 255
0
604-517 ImeDuplexEndS1
4SheetTooShortF
C
Fault counter for 82-146: IME
Media Path Sensor 14 sheet
too short
Number of faults
Range = 0 to 255
0
604-518 ImeDuplexEndS1
4LETimeoutFC
Fault counter for 82-147: IME
Media Path Sensor 14 LE tim
-
eout
Number of faults
Range = 0 to 255
0
604-519 ImeDuplexEndS1
4TETimeoutFC
Fault counter for 82-148: IME
Media Path Sensor 14 TE tim
-
eout
Number of faults
Range = 0 to 255
0
604-521 ImeDuplexEndS1
4LETimeoutFCa
Fault counter for 82-150: IME
Media Path Duplex Sensor 14
LE timeout
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
604-522 ImeDuplexEndS1
4TETimeoutFCa
Fault counter for 82-151: IME
Media Path Duplex Sensor 14
TE timeout
Number of faults
Range = 0 to 255
0
604-523 ImeVertTransMo-
tor (M2)Overcur-
rFC
Fault counter for 82-500: IME
M2 over current
Number of faults
Range = 0 to 255
0
604-524 ImeVertTransMo-
tor(M2)StalledFC
Fault Counter 82-501: IME
Vert Trans Motor (M2) stalled
Number of faults
Range = 0 to 255
0
604-525 ImeHorzTransMo-
tor (M6)Overcur-
rFC
Fault Counter 82-502: IME
Horiz Trans Motor (M6) over
current
Number of faults
Range = 0 to 255
0
604-526 ImeHorizTrans-
Motor(M6)Stalled
FC
Fault counter for 82-503: IME
M6 stalled
Number of faults
Range = 0 to 255
0
604-527 ImeNipCSolOver-
currFC
Fault counter for 82-507: IME
Nip C solenoid over current
Number of faults
Range = 0 to 255
0
604-528 ImeNipDSolOver-
currFC
Fault counter for 82-508: IME
Nip D solenoid over current
Number of faults
Range = 0 to 255
0
604-529 ImeTrailerCalc-
FailFC
Fault counter for 82-510: IME
Trailer slowdown calculation
fail
Number of faults
Range = 0 to 255
0
604-530 ImeMPS13Sheet
TooLongFC
Fault counter for 83-110: IME
Media Path Sensor 13 sheet
too long
Number of faults
Range = 0 to 255
0
604-531 ImeMPS13Sheet
To oSh or tF C
Fault counter for 83-111: IME
Media Path Sensor 13 sheet
too short
Number of faults
Range = 0 to 255
0
604-532 ImeMPInvS13Sh
eetTooLongFC
Fault counter for 83-112: IME
Media Path Invert Sensor 13
sheet too long
Number of faults
Range = 0 to 255
0
604-533 ImeDupStartInvS
13SheetTooShort
FC
Fault counter for 83-113: IME
Media Path Invert Sensor 13
sheet too short
Number of faults
Range = 0 to 255
0
604-534 ImeDupStartS13L
ETimeoutFC
Fault counter for 83-114: IME
Media Path Sensor 13 LE tim
-
eout
Number of faults
Range = 0 to 255
0
604-535 ImeDupStartS13T
ETimeoutFC
Fault Counter 83-115: IME
Duplex Start Sensor 13 TE tim
-
eout
Number of faults
Range = 0 to 255
0
604-536 ImeDupStartInvS
13LETimeoutFC
Fault Counter 83-116: IME
Duplex Start Invert Sensor 13
LE timeout
Number of faults
Range = 0 to 255
0
604-537 ImeDupStartInvS
13TETimeoutFC
Fault Counter 83-117: IME
Duplex Start Invert Sensor 13
TE timeout
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
