ColorQube® 9303 Family
dC131
General Procedures/Information
604-538 ImeExitMotor-
Fwd(M5)Overcur-
rFC
Fault counter for 83-500: IME
M5 over current
Number of faults
Range = 0 to 255
0
604-539 ImeDiverterSo-
lOvercurrFC
Fault counter for 83-504: IME
Diverter solenoid over current
Number of faults
Range = 0 to 255
0
604-540 ImeDuplexSo-
lOvercurrFC
Fault counter for 83-506: IME
Duplex solenoid over current
Number of faults
Range = 0 to 255
0
604-541 ImePreheatToo-
HotFC
Fault counter for 88-500: IME
Preheat heater is too hot
Number of faults
Range = 0 to 255
0
604-542 ImePreheat-
TooSlowFC
Fault counter for 88-501: IME
Preheat is heating too slow
Number of faults
Range = 0 to 255
0
604-543 ImePreheatTher-
mFailFC
Fault counter for 88-502: IME
Preheat thermistor failure
Number of faults
Range = 0 to 255
0
604-544 ImeRegAirPum-
pOverCurrFC
Fault counter for 88-508: IME
RALPH Air PuM Over Curr
Number of faults
Range = 0 to 255
0
604-545 ImeMPS10Sheet
TooLongFC
Fault counter for 89-110: IME
Media Path Sensor 10 sheet
too long
Number of faults
Range = 0 to 255
0
604-546 ImeMPS10Sheet
TooShortFC
Fault counter for 89-111: IME
Media Path Sensor 10 sheet
too Short
Number of faults
Range = 0 to 255
0
604-547 ImeMPS10LETim
eoutFC
Fault counter for 89-112: IME
Media Path Sensor 10 LE tim
-
eout
Number of faults
Range = 0 to 255
0
604-548 ImeMPS10TETim
eoutFC
Fault counter for 89-113: IME
Media Path Sensor 10 TE tim
-
eout
Number of faults
Range = 0 to 255
0
604-549 ImeMPS20Sheet
TooLongFC
Fault counter for 89-125: IME
Media Path Sensor 20 sheet
too Long
Number of faults
Range = 0 to 255
0
604-550 ImeMPS20Sheet
TooShortFC
Fault counter for 89-126: IME
Media Path Sensor 20 sheet
too Short
Number of faults
Range = 0 to 255
0
604-551 ImeMPS20LETim
eoutFC
Fault counter for 89-127: IME
Media Path Sensor 20 LE tim
-
eout
Number of faults
Range = 0 to 255
0
604-552 ImeMPS20TETim
eoutFC
Fault counter for 89-128: IME
Media Path Sensor 20 TE tim
-
eout
Number of faults
Range = 0 to 255
0
604-553 ImeMPSheet-
TooTateAtNipAFC
Fault counter for 89-129: IME
Media Path sheet too tate at
Nip A
Number of faults
Range = 0 to 255
0
604-554 ImeM3_1Overcur
rFC
Fault counter for 89-500: IME
M3_1 over current
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
604-555 ImeM3_2Overcur
rFC
Fault counter for 89-502: IME
M3_2 over current
Number of faults
Range = 0 to 255
0
604-556 ImeLatDriveOver-
currFC
Fault counter for 89-504: IME
Lat sensor drive over current
Number of faults
Range = 0 to 255
0
604-560 ImeStanceSen-
sorTimeoutFC
Fault counter for 89-520: IME
Stance sensor timeout
Number of faults
Range = 0 to 255
0
604-562 ImeRegFailedDe-
tectLat-
eralEdgeFC
Fault counter for 89-531: IME
Registration Scanner failed to
detect lateral edge
Number of faults
Range = 0 to 255
0
604-563 ImeScanTimed-
OutFC
Fault counter for 89-532: IME
Scan timed out and failed to
complete normally
Number of faults
Range = 0 to 255
0
604-564 ImeRegProc-
FailFC
Fault counter for 89-540: IME
Registration processing failure
Number of faults
Range = 0 to 255
0
604-565 ImeRegProcLE-
NotDetectedFC
Fault counter for 89-541: IME
Registration processing lead
-
ing edge not detected
Number of faults
Range = 0 to 255
0
604-566 ImeRegProcLat-
EdgeNotDetFC
Fault counter for 89-542: IME
Registration processing lateral
edge not detected
Number of faults
Range = 0 to 255
0
604-567 ImeRegPro-
cLEErrFC
Fault counter for 89-543: IME
Registration processing lead
-
ing edge error
Number of faults
Range = 0 to 255
0
604-568 ImeRegProcLat-
eralEdgeErrFC
Fault counter for 89-544: IME
Registration processing lateral
edge error
Number of faults
Range = 0 to 255
0
604-569 ImeRegProcLE-
Crossing-
To Sm all FC
Fault counter for 89-545: IME
Registration processing lead
-
ing edge crossing to small
Number of faults
Range = 0 to 255
0
604-570 ImeRegSkewEx-
cessiveFC
Fault counter for 89-550: IME
Registration skew excessive
Number of faults
Range = 0 to 255
0
604-571 ImeRegOffsetEx-
cessiveFC
Fault counter for 89-551: IME
Registration offset excessive
Number of faults
Range = 0 to 255
0
604-572 ImeHeadInitPos-
ErrFC
Fault counter for 91-500: IME
Printheads initial position error
Number of faults
Range = 0 to 255
0
604-573 ImeHeadImag-
ingTimingErrFC
Fault counter for 91-501: IME
Printheads imaging timing
error
Number of faults
Range = 0 to 255
0
604-574 ImeMarkingSe-
quenceTimingEr-
rFC
Fault counter for 91-502: IME
Marking sequence timing error
Number of faults
Range = 0 to 255
0
604-575 ImePrintImage-
DataTimeoutFC
Fault counter for 91-503: IME
Print image data timeout
Number of faults
Range = 0 to 255
0
604-576 ImeHead3StitchO
vercurrFC
Fault counter for 91-504: IME
Printhead 3 stitch over current
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
