Xerox ColorQube 9301

February 2013
6-163
ColorQube® 9303 Family
dC131
General Procedures/Information
604-577 ImeHead4StitchO
vercurrFC
Fault counter for 91-505: IME
Printhead 4 stitch over current
Number of faults
Range = 0 to 255
0
604-578 ImeHead1RollOv
ercurrFC
Fault counter for 91-506: IME
Printhead 1 roll over current
Number of faults
Range = 0 to 255
0
604-579 ImeHead2RollOv
ercurrFC
Fault counter for 91-507: IME
Printhead 2 roll over current
Number of faults
Range = 0 to 255
0
604-580 ImeHead3RollOv
ercurrFC
Fault counter for 91-508: IME
Printhead 3 roll over current
Number of faults
Range = 0 to 255
0
604-581 ImeHead4RollOv
ercurrFC
Fault counter for 91-509: IME
Printhead 4 roll over current
Number of faults
Range = 0 to 255
0
604-582 ImeUpperX-
AOvercurrFC
Fault counter for 91-510: IME
Upper XA over current
Number of faults
Range = 0 to 255
0
604-583 ImeLowerX-
AOvercurrFC
Fault counter for 91-511: IME
Lower XA over current
Number of faults
Range = 0 to 255
0
604-584 ImeCarriageDri-
veOvercurrFC
Fault counter for 91-512: IME
Carriage drive over current
Number of faults
Range = 0 to 255
0
604-585 ImeIODDriveO-
vercurrFC
Fault counter for 91-513: IME
IOD drive over current
Number of faults
Range = 0 to 255
0
604-586 ImeIODDriveS-
tallFC
Fault counter for 91-514: IME
IOD drive stall
Number of faults
Range = 0 to 255
0
604-587 ImeHMVertOver-
currFC
Fault counter for 91-515: IME
HM vertical over current
Number of faults
Range = 0 to 255
0
604-588 ImeLowPressure-
AssistOvercurrFC
Fault counter for 91-516: IME
Low Pressure Assist over cur
-
rent
Number of faults
Range = 0 to 255
0
604-589 ImeMUAirPu-
mOvercurrFC
Fault counter for 91-517: IME
MU Air Pum over current
Number of faults
Range = 0 to 255
0
604-591 ImeHead1Nvram
ErrFC
Fault counter for 91-519: IME
Printhead 1 NVRam error
Number of faults
Range = 0 to 255
0
604-592 ImeHead2Nvram
ErrFC
Fault counter for 91-520: IME
Printhead 2 NVRam error
Number of faults
Range = 0 to 255
0
604-593 ImeHead3Nvram
ErrFC
Fault counter for 91-521: IME
Printhead 3 NVRam error
Number of faults
Range = 0 to 255
0
604-594 ImeHead4Nvram
ErrFC
Fault counter for 91-522: IME
Printhead 4 NVRam error
Number of faults
Range = 0 to 255
0
604-595 ImeHead1LHeate
rTooHotFC
Fault counter for 91-523: IME
Printhead 1 left jet heater is too
hot
Number of faults
Range = 0 to 255
0
604-596 ImeHead2LHeate
rTooHotFC
Fault counter for 91-524: IME
Printhead 2 left jet heater is too
hot
Number of faults
Range = 0 to 255
0
604-597 ImeHead3LHeate
rTooHotFC
Fault counter for 91-525: IME
Printhead 3 left jet heater is too
hot
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
604-598 ImeHead4LHeate
rTooHotFC
Fault counter for 91-526: IME
Printhead 4 left jet heater is too
hot
Number of faults
Range = 0 to 255
0
604-599 ImeHead1LHeate
rTooSlowFC
Fault counter for 91-527: IME
Printhead 1 left jet heater is too
slow
Number of faults
Range = 0 to 255
0
604-600 ImeHead2LHeate
rTooSlowFC
Fault Counter 91-528: IME
Print Head 2 left jet heater is
too slow
Number of fault-
sRange = 0 to 255
0
604-601 ImeHead3LHeate
rTooSlowFC
Fault counter for 91-529: IME
Printhead 3 left jet heater is too
slow
Number of faults
Range = 0 to 255
0
604-602 ImeHead4LHeate
rTooSlowFC
Fault counter for 91-530: IME
Printhead 4 left jet heater is too
slow
Number of faults
Range = 0 to 255
0
604-603 meHead1LeftThe
rmBadReadingFC
Fault counter for 91-531: IME
Printhead 1 left jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-604 ImeHead2LeftThe
rmBadReadingFC
Fault counter for 91-532: IME
Printhead 2 left jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-605 ImeHead3LeftThe
rmBadReadingFC
Fault counter for 91-533: IME
Printhead 3 left jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-606 ImeHead4LeftThe
rmBadReadingFC
Fault counter for 91-534: IME
Printhead 4 left jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-607 ImeHead1RHeate
rTooHotFC
Fault counter for 91-535: IME
Printhead 1 right jet heater too
hot
Number of faults
Range = 0 to 255
0
604-608 ImeHead2RHeate
rTooHotFC
Fault counter for 91-536: IME
Printhead 2 right jet heater too
hot
Number of faults
Range = 0 to 255
0
604-609 ImeHead3RHeate
rTooHotFC
Fault counter for 91-537: IME
Printhead 3 right jet heater too
hot
Number of faults
Range = 0 to 255
0
604-610 ImeHead4RHeate
rTooHotFC
Fault counter for 91-538: IME
Printhead 4 right jet heater too
hot
Number of faults
Range = 0 to 255
0
604-611 ImeHead1RHeate
rTooSlowFC
Fault counter for 91-539: IME
Printhead 1 right jet heater too
slow
Number of faults
Range = 0 to 255
0
604-612 ImeHead2RHeate
rTooSlowFC
Fault counter for 91-540: IME
Printhead 2 right jet heater too
slow
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
