Xerox ColorQube 9301

February 2013
6-164
ColorQube® 9303 Family
dC131
General Procedures/Information
604-613 ImeHead3RHeate
rTooSlowFC
Fault counter for 91-541: IME
Printhead 3 right jet heater too
slow
Number of faults
Range = 0 to 255
0
604-614 ImeHead4RHeate
rTooSlowFC
Fault counter for 91-542: IME
Printhead 4 right jet heater too
slow
Number of faults
Range = 0 to 255
0
604-615 ImeHead1RightT
hermBadRead
-
ingFC
Fault counter for 91-543: IME
Printhead 1 right jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-616 ImeHead2RightT
hermBadRead
-
ingFC
Fault counter for 91-544: IME
Printhead 2 right jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-617 ImeHead3RightT
hermBadRead
-
ingFC
Fault counter for 91-545: IME
Printhead 3 right jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-618 ImeHead4RightT
hermBadRead
-
ingFC
Fault counter for 91-546: IME
Printhead 4 right jet thermistor
bad reading
Number of faults
Range = 0 to 255
0
604-619 ImeHead1ResHe
aterTooHotFC
Fault counter for 91-547: IME
Printhead 1 reservoir heater
too hot
Number of faults
Range = 0 to 255
0
604-620 ImeHead2ResHe
aterTooHotFC
Fault counter for 91-548: IME
Printhead 2 reservoir heater
too hot
Number of faults
Range = 0 to 255
0
604-621 ImeHead3ResHe
aterTooHotFC
Fault counter for 91-549: IME
Printhead 3 reservoir heater
too hot
Number of faults
Range = 0 to 255
0
604-622 ImeHead4ResHe
aterTooHotFC
Fault counter for 91-550: IME
Printhead 4 reservoir heater
too hot
Number of faults
Range = 0 to 255
0
604-623 ImeHead1ResHe
aterTooSlowFC
Fault counter for 91-551: IME
Printhead 1 reservoir heater
too slow
Number of faults
Range = 0 to 255
0
604-624 ImeHead2ResHe
aterTooSlowFC
Fault counter for 91-552: IME
Printhead 2 reservoir heater
too slow
Number of faults
Range = 0 to 255
0
604-625 ImeHead3ResHe
aterTooSlowFC
Fault counter for 91-553: IME
Printhead 3 reservoir heater
too slow
Number of faults
Range = 0 to 255
0
604-626 ImeHead4ResHe
aterTooSlowFC
Fault counter for 91-554: IME
Printhead 4 reservoir heater
too slow
Number of faults
Range = 0 to 255
0
604-627 ImeHead1ResHe
aterThermBadFC
Fault counter for 91-555: IME
Printhead 1 reservoir heater
thermistor bad
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
604-628 ImeHead2ResHe
aterThermBadFC
Fault counter for 91-556: IME
Printhead 2 reservoir heater
thermistor bad
Number of faults
Range = 0 to 255
0
604-629 ImeHead3ResHe
aterThermBadFC
Fault counter for 91-557: IME
Printhead 3 reservoir heater
thermistor bad
Number of faults
Range = 0 to 255
0
604-630 ImeHead4ResHe
aterThermBadFC
Fault counter for 91-558: IME
Printhead 4 reservoir heater
thermistor bad
Number of faults
Range = 0 to 255
0
604-631 ImeMD-
SysWrong-
StateFC
Fault counter for 91-559: IME
MD Manager, System not in
correct state for requested ser
-
vice
Number of faults
Range = 0 to 255
0
604-632 ImeHeadCarriag-
eTimeoutFC
Fault counter for 91-560: IME
Printhead carriage timeout
Number of faults
Range = 0 to 255
0
604-634 ImeHeadCar-
riageNoEdge-
FoundFC
Fault counter for 91-562: IME
Printhead Carriage no edge
found
Number of faults
Range = 0 to 255
0
604-635 ImeUpperHead-
CarrUnexpect-
EvtFC
Fault counter for 91-563: IME
Upper Printhead Carriage
unexpected event
Number of faults
Range = 0 to 255
0
604-636 ImeUpperHead-
CarrTOMovRe-
strFC
This NVM ID shown for infor-
mation only. The machine
does not have carriage
restraint motors.
Number of faults
Range = 0 to 255
0
604-637 ImeUpperHead-
CarrRestrStallFC
This NVM ID shown for infor-
mation only. The machine
does not have carriage
restraint motors.
Number of faults
Range = 0 to 255
0
604-638 ImeLowerHead-
CarrNoEdge-
FoundFC
Fault counter for 91-567: IME
Lower Printhead Carriage no
edge found
Number of faults
Range = 0 to 255
0
604-639 ImeLowerHead-
CarrUnexpect-
EvFC
Fault counter for 91-568: IME
Lower Printhead Carriage
unexpected event
Number of faults
Range = 0 to 255
0
604-640 ImeLowerHead-
CarrTOMovRe-
strFC
This NVM ID shown for infor-
mation only. The machine
does not have carriage
restraint motors.
Number of faults
Range = 0 to 255
0
604-641 ImeLowerHead-
CarrRestrStallFC
This NVM ID shown for infor-
mation only. The machine
does not have carriage
restraint motors.
Number of faults
Range = 0 to 255
0
604-642 ImeHeadWiper-
VertNoEdgeFC
Fault counter for 91-572: IME
Printhead wiper vertical motion
edge not found
Number of faults
Range = 0 to 255
0
Table 11 CCS NVM ID 604-300 to 604-656
NVM ID NVM Name NVM Description Settings Default
