ColorQube® 9303 Family
dC131
General Procedures/Information
608-317 FanDrumCooling-
ShortFC
Fault Counter 99-721-00: FAN-
DRUMCOOLINGSHORT
Number of faults
Range = 0 to 255
0
608-318 FanAbatement-
ShortFC
Fault Counter 99-726-00:
FANABATEMENTSHORT
Number of faults
Range = 0 to 255
0
608-319 PumpReg/Pre-
heatAirPumpsS-
hortFC
Fault Counter 99-731-00:
PUMPReg/PreheatAIR
-
PUMPSSHORT
Number of faults
Range = 0 to 255
0
608-320 ThermistorMedi-
aPreheatOpenFC
Fault Counter 99-735-00:
THERMISTORMEDIAPRE
-
HEATOPEN
Number of faults
Range = 0 to 255
0
608-321 ThermistorMedi-
aPreheatShortFC
Fault Counter 99-736-00:
THERMISTORMEDIAPRE
-
HEATSHORT
Number of faults
Range = 0 to 255
0
608-322 SolenoidCARDi-
verterOpenFC
Fault Counter 99-740-00:
SOLENOIDCARDIVERTERO
-
PEN
Number of faults
Range = 0 to 255
0
608-323 SolenoidCARDi-
verterShortFC
Fault Counter 99-741-00:
SOLENOIDCARDIVERTER
-
SHORT
Number of faults
Range = 0 to 255
0
608-324 SolenoidDuplex-
OpenFC
Fault Counter 99-745-00:
SOLENOIDDUPLEXOPEN
Number of faults
Range = 0 to 255
0
608-325 SolenoidDuplex-
ShortFC
Fault Counter 99-746-00:
SOLENOIDDUPLEXSHORT
Number of faults
Range = 0 to 255
0
608-326 SolenoidNip-
COpenFC
Fault Counter 99-750-00:
SOLENOIDNIPCOPEN
Number of faults
Range = 0 to 255
0
608-327 SolenoidNipC-
ShortFC
Fault Counter 99-751-00:
SOLENOIDNIPCSHORT
Number of faults
Range = 0 to 255
0
608-328 SolenoidNip-
DOpenFC
Fault Counter 99-755-00:
SOLENOIDNIPDOPEN
Number of faults
Range = 0 to 255
0
608-329 SolenoidNipD-
ShortFC
Fault Counter 99-756-00:
SOLENOIDNIPDSHORT
Number of faults
Range = 0 to 255
0
608-330 SolenoidNi-
pEOpenFC
Fault Counter 99-760-00:
SOLENOIDNIPEOPEN
Number of faults
Range = 0 to 255
0
608-331 SolenoidNipE-
ShortFC
Fault Counter 99-761-00:
SOLENOIDNIPESHORT
Number of faults
Range = 0 to 255
0
608-332 SolenoidStripper-
OpenFC
Fault Counter 99-765-00:
SOLENOIDSTRIPPEROPEN
Number of faults
Range = 0 to 255
0
608-333 SolenoidStripper-
ShortFC
Fault Counter 99-766-00:
SOLENOIDSTRIPPERSHORT
Number of faults
Range = 0 to 255
0
608-334 SolenoidWasteT-
rayLockShortFC
Fault Counter 99-771-00:
SOLENOIDWASTETRAY
-
LOCKSHORT
Number of faults
Range = 0 to 255
0
608-335 SolenoidClea-
nUnitValveO-
penFC
Fault Counter 99-775-00:
SOLENOIDCleanUnitVALVE
-
OPEN
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
608-336 SolenoidClea-
nUnitValve-
ShortFC
Fault Counter 99-776-00:
SOLENOIDCleanUnitVALVE
-
SHORT
Number of faults
Range = 0 to 255
0
608-337 PumpCleanUnit-
DeliveryOpenFC
Fault Counter 99-780-00:
PUMPCleanUnitDELIVERY
-
OPEN
Number of faults
Range = 0 to 255
0
608-338 PumpCleanUnit-
DeliveryShortFC
Fault Counter 99-781-00:
PUMPCleanUnitDELIVERY
-
SHORT
Number of faults
Range = 0 to 255
0
608-339 PumpCleanUni-
tReturnOpenFC
Fault Counter 99-785-00:
PUMPCleanUnitRETURN
-
OPEN
Number of faults
Range = 0 to 255
0
608-340 PumpCleanUni-
tReturnShortFC
Fault Counter 99-786-00:
PUMPCleanUnitRETURN
-
SHORT
Number of faults
Range = 0 to 255
0
608-341 ADCCleanUni-
tOilResLevse-
nOpenFC
Fault Counter 99-790-00:
SENSORADCCleanUnitOIL
-
RESLEVELSENSEOPEN
Number of faults
Range = 0 to 255
0
608-342 SenADCClea-
nUnitpresssen-
sOpenFC
Fault Counter 99-791-00:
SENSORADCCleanUnit
-
PRESSURESENSEOPEN
Number of faults
Range = 0 to 255
0
608-343 ADCCleanUni-
tOilResLevSen-
ShortFC
Fault Counter 99-792-00:
SENSORADCCleanUnitOIL
-
RESLEVELSENSESHORT
Number of faults
Range = 0 to 255
0
608-344 SenADCClea-
nUnitpresssensS-
hortFC
Fault Counter 99-793-00:
SENSORADCCleanUnit
-
PRESSURESENSESHORT
Number of faults
Range = 0 to 255
0
608-345 SenCleanUnitI-
buttonIICfail
-
ureFC
Fault Counter 99-795-00:
SENSORCleanUnitIBUTTONI
-
ICFAILURE
Number of faults
Range = 0 to 255
0
608-346 SenCleanUnitI-
buttPresfailureFC
Fault Counter 99-796-00:
SENSORCleanUnitIBUTTON
-
PRESENTFAILURE
Number of faults
Range = 0 to 255
0
608-347 MotorDrumMain-
tOpenFC
Fault Counter 99-801-00:
MOTORDRUMMAINTOPEN
Number of faults
Range = 0 to 255
0
608-348 MotorDrumMaint-
ShortFC
Fault Counter 99-802-00:
MOTORDRUMMAINTSHORT
Number of faults
Range = 0 to 255
0
608-349 MotorDrumMain-
tEncoderFC
Fault Counter 99-803-00:
MOTORDRUMMAINTEN
-
CODER
Number of faults
Range = 0 to 255
0
608-350 MotorHeadRoll1S
hortFC
Fault Counter 99-811-00:
MOTORHEADROLL1SHORT
Number of faults
Range = 0 to 255
0
608-351 MotorHeadRoll2S
hortFC
Fault Counter 99-813-00:
MOTORHEADROLL2SHORT
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
