Xerox ColorQube 9301 - Page 1508

February 2013
6-216
ColorQube® 9303 Family
dC131
General Procedures/Information
608-352 MotorHeadRoll3S
hortFC
Fault Counter 99-815-00:
MOTORHEADROLL3SHORT
Number of faults
Range = 0 to 255
0
608-353 MotorHeadRoll4S
hortFC
Fault Counter 99-817-00:
MOTORHEADROLL4SHORT
Number of faults
Range = 0 to 255
0
608-354 MotorHeadStitch3
ShortFC
Fault Counter 99-821-00:
MOTORHEADSTITCH3SHOR
T
Number of faults
Range = 0 to 255
0
608-355 MotorHeadStitch4
ShortFC
Fault Counter 99-823-00:
MOTORHEADSTITCH4SHOR
T
Number of faults
Range = 0 to 255
0
608-356 MotorCar-
rRestraintLower-
ShortFC
This NVM ID shown for infor-
mation only. The machine
does not have carriage
restraint motors.
Number of faults
Range = 0 to 255
0
608-357 MotorCar-
rRestraintUpper-
ShortFC
This NVM ID shown for infor-
mation only. The machine
does not have carriage
restraint motors.
Number of faults
Range = 0 to 255
0
608-358 MotorCarriageSe-
lectOpenFC
Fault Counter 99-830-00:
MOTORCARRIAGESELEC
-
TOPEN
Number of faults
Range = 0 to 255
0
608-359 MotorCarriageSe-
lectShortFC
Fault Counter 99-831-00:
MOTORCARRIAGESELECT
-
SHORT
Number of faults
Range = 0 to 255
0
608-360 MotorCarriagedri-
veOpenFC
Fault Counter 99-832-00:
MOTORCARRIAGEDRIVEO
-
PEN
Number of faults
Range = 0 to 255
0
608-361 MotorCar-
riagedrive-
ShortFC
Fault Counter 99-833-00:
MOTORCARRIAGEDRIVE
-
SHORT
Number of faults
Range = 0 to 255
0
608-362 MotorHead-
MaintVertica-
lOpenFC
Fault Counter 99-835-00:
MOTORHEADMAINTVERTI
-
CALOPEN
Number of faults
Range = 0 to 255
0
608-363 MotorHead-
MaintVerti-
calShortFC
Fault Counter 99-836-00:
MOTORHEADMAINTVERTI
-
CALSHORT
Number of faults
Range = 0 to 255
0
608-364 MotorHeadMain-
tHorizonta-
lOpenFC
Fault Counter 99-837-00:
MOTORHEADMAINTHORI
-
ZONTALOPEN
Number of faults
Range = 0 to 255
0
608-365 MotorHeadMain-
tHorizontal-
ShortFC
Fault Counter 99-838-00:
MOTORHEADMAINTHORI
-
ZONTALSHORT
Number of faults
Range = 0 to 255
0
608-366 MotorXaxisUp-
perOpenFC
Fault Counter 99-840-00:
MOTORXAXISUPPEROPEN
Number of faults
Range = 0 to 255
608-367 MotorXaxisUp-
perShortFC
Fault Counter 99-841-00:
MOTORXAXISUPPERSHORT
Number of faults
Range = 0 to 255
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
608-368 MotorXaxisLow-
erOpenFC
Fault Counter 99-845-00:
MOTORXAXISLOWEROPEN
Number of faults
Range = 0 to 255
608-369 MotorXaxisLow-
erShortFC
Fault Counter 99-846-00:
MOTORXAXISLOWER
-
SHORT
Number of faults
Range = 0 to 255
608-370 MotorIODShuttle-
ShortFC
Fault Counter 99-861-00:
MOTORIODSHUTTLESHORT
Number of faults
Range = 0 to 255
608-371 MotorInkSKUSh-
ortFC
Fault Counter 99-871-00:
MOTORINKSKUSHORT
Number of faults
Range = 0 to 255
608-372 MotorInkLoad-
BeltDriveShortFC
Fault Counter 99-876-00:
MOTORINKLOADBELT
-
DRIVESHORT
Number of faults
Range = 0 to 255
608-373 MotorDrumDrive-
OpenFC
Fault Counter 99-880-00:
MOTORDRUMDRIVEOPEN
Number of faults
Range = 0 to 255
608-374 MotorDrumDrive-
ShortFC
Fault Counter 99-881-00:
MOTORDRUMDRIVESHORT
Number of faults
Range = 0 to 255
608-375 MotorDrumDrive-
MotorEncoderFC
Fault Counter 99-884-00:
MOTORDRUMDRIVEMO
-
TORENCODER
Number of faults
Range = 0 to 255
608-376 MotorDrumDrive-
DrumEncoderFC
Fault Counter 99-885-00:
MOTORDRUMDRIVEDRU
-
MENCODER
Number of faults
Range = 0 to 255
608-377 MotorTransfix-
FrontForceEn-
coderFC
Fault Counter 99-888-00:
MOTORTRANSFIXFRONT
-
FORCEENCODER
Number of faults
Range = 0 to 255
608-378 MotorTrans-
fixRearForceEn-
coderFC
Fault Counter 99-889-00:
MOTORTRANSFIXREAR
-
FORCEENCODER
Number of faults
Range = 0 to 255
608-379 MotorTransfixFr-
ontOpenFC
Fault Counter 99-890-00:
MOTORTRANSFIXFRON
-
TOPEN
Number of faults
Range = 0 to 255
608-380 MotorTransfix-
FrontShortFC
Fault Counter 99-891-00:
MOTORTRANSFIXFRONT
-
SHORT
Number of faults
Range = 0 to 255
608-381 MotorTransfix-
FrontMotorEn-
coderFC
Fault Counter 99-892-00:
MOTORTRANSFIXFRONT
-
MOTORENCODER
Number of faults
Range = 0 to 255
608-382 MotorTrans-
fixRearOpenFC
Fault Counter 99-895-00:
MOTORTRANSFIXREARO
-
PEN
Number of faults
Range = 0 to 255
608-383 MotorTrans-
fixRearShortFC
Fault Counter 99-896-00:
MOTORTRANSFIXREAR
-
SHORT
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
