Xerox ColorQube 9301 - Page 1512

February 2013
6-220
ColorQube® 9303 Family
dC131
General Procedures/Information
608-522 Cyan - Metere-
dExp - SoldDet
Cyan Metered ink stick
expected, Sold detected
Range = 0 to 65535 0
608-523 Magenta -
MeteredExp - Sol
-
dDet
Magenta Metered ink stick
expected, Sold detected
Range = 0 to 65535 0
608-524 Yellow - Metere-
dExp - SoldDet
Yellow Metered ink stick
expected, Sold detected
Range = 0 to 65535 0
608-525 Black - Metere-
dExp - DMODet
Black Metered ink stick
expected, DMO detected
Range = 0 to 65535 0
608-526 Cyan - Metere-
dExp - DMODet
Cyan Metered ink stick
expected, DMO detected
Range = 0 to 65535 0
608-527 Magenta -
MeteredExp -
DMODet
Magenta Metered ink stick
expected, DMO detected
Range = 0 to 65535 0
608-528 Yellow - Metere-
dExp - DMODet
Yellow Metered ink stick
expected, DMO detected
Range = 0 to 65535 0
608-529 Black - SoldExp -
MeteredDet
Black Sold ink stick expected,
Metered detected
Range = 0 to 65535 0
608-530 Cyan - SoldExp -
MeteredDet
Cyan Sold ink stick expected,
Metered detected
Range = 0 to 65535 0
608-531 Magenta Sold ink
stick expected,
Metered detected
Magenta - SoldExp - Metered-
Det
Range = 0 to 65535 0
608-532 Yellow - SoldExp -
MeteredDet
Yellow Sold ink stick expected,
Metered detected
Range = 0 to 65535 0
608-533 Black - SoldExp -
DMODet
Black Sold ink stick expected,
DMO detected
Range = 0 to 65535 0
608-534 Cyan - SoldExp -
DMODet
Cyan Sold ink stick expected,
DMO detected
Range = 0 to 65535 0
608-535 Magenta - Sol-
dExp - DMODet
Magenta Sold ink stick
expected, DMO detected
Range = 0 to 65535 0
608-536 Yellow - SoldExp -
DMODet
Yellow Sold ink stick expected,
DMO detected
Range = 0 to 65535 0
608-537 Black - DMOExp -
MeteredDet
Black DMO ink stick expected,
Metered detected
Range = 0 to 65535 0
608-538 Cyan - DMOExp -
MeteredDet
Cyan DMO ink stick expected,
Metered detected
Range = 0 to 65535 0
608-539 Magenta -
DMOExp -
MeteredDet
Magenta DMO ink stick
expected, Metered detected
Range = 0 to 65535 0
608-540 Yellow - DMOExp
- MeteredDet
Yellow DMO ink stick
expected, Metered detected
Range = 0 to 65535 0
608-541 Black - DMOExp -
SoldDet
Black DMO ink stick expected,
Sold detected
Range = 0 to 65535 0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
608-542 Cyan - DMOExp -
SoldDet
Cyan DMO ink stick expected,
Sold detected
Range = 0 to 65535 0
608-543 Magenta -
DMOExp - Sold
-
Det
Magenta DMO ink stick
expected, Sold detected
Range = 0 to 65535 0
608-544 Yellow - DMOExp
- SoldDet
Yellow DMO ink stick
expected, Sold detected
Range = 0 to 65535 0
608-545 Black - Unknown
type Det
Black unsupported ink stick
type detected
Range = 0 to 65535 0
608-546 Cyan - Unknown
type Det
Cyan unsupported ink stick
type detected
Range = 0 to 65535 0
608-547 Magenta -
Unknown type
Det
Magenta unsupported ink stick
type detected
Range = 0 to 65535 0
608-548 Yellow - Unknown
type Det
Yellow unsupported ink stick
type detected
Range = 0 to 65535 0
608-549 WaveAmpCableV
PPHead1Open
Fault Counter 99-080-00:
WaveAmpCableVPPHead1Op
en
Number of faults
Range = 0 to 255
0
608-550 WaveAmpCableV
PPHead2Open
Fault Counter 99-081-00:
WaveAmpCableVPPHead2Op
en
Number of faults
Range = 0 to 255
0
608-551 WaveAmpCableV
PPHead3Open
Fault Counter 99-082-00:
WaveAmpCableVPPHead3Op
en
Number of faults
Range = 0 to 255
0
608-552 WaveAmpCableV
PPHead4Open
Fault Counter 99-083-00:
WaveAmpCableVPPHead4Op
en
Number of faults
Range = 0 to 255
0
608-553 WaveAmpCableV
SSHead1Open
Fault Counter 99-084-00:
WaveAmpCableVSSHead1Op
en
Number of faults
Range = 0 to 255
0
608-554 WaveAmpCableV
SSHead2Open
Fault Counter 99-085-00:
WaveAmpCableVSSHead2Op
en
Number of faults
Range = 0 to 255
0
608-555 WaveAmpCableV
SSHead3Open
Fault Counter 99-086-00:
WaveAmpCableVSSHead3Op
en
Number of faults
Range = 0 to 255
0
608-556 WaveAmpCableV
SSHead4Open
Fault Counter 99-087-00:
WaveAmpCableVSSHead4Op
en
Number of faults
Range = 0 to 255
0
608-557 WaveAmpCableV
PPHead1Short
Fault Counter 99-088-00:
WaveAmpCableVPPHead1Sh
ort
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
