Xerox ColorQube 9301 - Page 1513

February 2013
6-221
ColorQube® 9303 Family
dC131
General Procedures/Information
608-558 WaveAmpCableV
PPHead2Short
Fault Counter 99-089-00:
WaveAmpCableVPPHead2Sh
ort
Number of faults
Range = 0 to 255
0
608-559 WaveAmpCableV
PPHead3Short
Fault Counter 99-090-00:
WaveAmpCableVPPHead3Sh
ort
Number of faults
Range = 0 to 255
0
608-560 WaveAmpCableV
PPHead4Short
Fault Counter 99-091-00:
WaveAmpCableVPPHead4Sh
ort
Number of faults
Range = 0 to 255
0
608-561 WaveAmpCableV
SSead1Short
Fault Counter 99-092-00:
WaveAmpCableVSSead1Shor
t
Number of faults
Range = 0 to 255
0
608-562 WaveAmpCableV
SSHead2Short
Fault Counter 99-093-00:
WaveAmpCableVSSHead2Sh
ort
Number of faults
Range = 0 to 255
0
608-563 WaveAmpCableV
SSHead3Short
Fault Counter 99-094-00:
WaveAmpCableVSSHead3Sh
ort
Number of faults
Range = 0 to 255
0
608-564 WaveAmpCableV
SSHead4Short
Fault Counter 99-095-00:
WaveAmpCableVSSHead4Sh
ort
Number of faults
Range = 0 to 255
0
608-729 IOD Excessive
H1 X pos noise
Fault Counter 99-929-00: IOD
excessive head 1 X position
noise
Number of faults
Range = 0 to 255
0
608-730 IOD Excessive
H2 X pos noise
Fault Counter 99-930-00: IOD
excessive head 2 X position
noise
Number of faults
Range = 0 to 255
0
608-731 IOD Excessive
H3 X pos noise
Fault Counter 99-931-00: IOD
excessive head 3 X position
noise
Number of faults
Range = 0 to 255
0
608-732 IOD Excessive
H4 X pos noise
Fault Counter 99-932-00: IOD
excessive head 4 X position
noise
Number of faults
Range = 0 to 255
0
608-733 IOD Excessive
H1 Y pos noise
Fault Counter 99-933-00: IOD
excessive head 1 Y position
noise
Number of faults
Range = 0 to 255
0
608-734 IOD Excessive
H2 Y pos noise
Fault Counter 99-934-00: IOD
excessive head 2 Y position
noise
Number of faults
Range = 0 to 255
0
608-735 IOD Excessive
H3 Y pos noise
Fault Counter 99-935-00: IOD
excessive head 3 Y position
noise
Number of faults
Range = 0 to 255
0
608-736 IOD Excessive
H4 Y pos noise
Fault Counter 99-936-00: IOD
excessive head 4 Y position
noise
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
608-737 IOD Excessive
H1 roll pos noise
Fault Counter 99-937-00: IOD
excessive head 1 roll position
noise
Number of faults
Range = 0 to 255
0
608-738 IOD Excessive
H2 roll pos noise
Fault Counter 99-938-00: IOD
excessive head 2 roll position
noise
Number of faults
Range = 0 to 255
0
608-739 IOD Excessive
H3 roll pos noise
Fault Counter 99-939-00: IOD
excessive head 3 roll position
noise
Number of faults
Range = 0 to 255
0
608-740 IOD Excessive
H4 roll pos noise
Fault Counter 99-940-00: IOD
excessive head 4 roll position
noise
Number of faults
Range = 0 to 255
0
608-833 ImeCleaningUnit-
EoIFC
Fault counter 94-629-00 IME
cleaning unit EOL due to gel
Number of faults
Range = 0 to 255
0
608-835 TTM1 TE Late at
TAR
Fault counter 71-130-00 Number of faults
Range = 0 to 255
0
608-836 TTM1 LE Too
Early at TAR
Fault counter 71-132-00 Number of faults
Range = 0 to 255
0
608-837 TTM1 Too Long
At TAR
Fault counter 71-150-00 Number of faults
Range = 0 to 255
0
608-838 TTM1 Too Short
At TAR
Fault counter 71-151-00 Number of faults
Range = 0 to 255
0
608-839 TTM1 Too Long
at TAR NoAu
-
toPurge
Fault counter 71-152-00 Number of faults
Range = 0 to 255
0
608-840 TTM1 TooShort at
TAR NoAu
-
toPurge
Fault counter 71-153-00 Number of faults
Range = 0 to 255
0
608-841 TTM2 TE Late at
TAR
Fault counter 72-130-00 Number of faults
Range = 0 to 255
0
608-842 TTM2 LE Late at
TAR1
Fault counter 72-131-00 Number of faults
Range = 0 to 255
0
608-843 TTM2 LE Too
Early at TAR
Fault counter 72-132-00 Number of faults
Range = 0 to 255
0
608-844 TTM2 LE Too
Early at TAR1
Fault counter 72-133-00 Number of faults
Range = 0 to 255
0
608-845 TTM2 Too Long
At TAR
Fault counter 72-150-00 Number of faults
Range = 0 to 255
0
608-846 TTM2 Too Short
At TAR
Fault counter 72-151-00 Number of faults
Range = 0 to 255
0
608-847 TTM2 Too Long
at TAR NoAu
-
toPurge
Fault counter 72-152-00 Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
