Xerox ColorQube 9301

February 2013
6-235
ColorQube® 9303 Family
dC131
General Procedures/Information
620-106 ADF Major Ver-
sion
Range = 0 to 65535 0
620-107 ADF Minor Ver-
sion
Range = 0 to 65535 0
620-108 ADF Revision
Version
Range = 0 to 65535 0
620-109 ADF Patch Ver-
sion
Range = 0 to 65535 0
620-110 IPL Version Range = 0 to 65535 0
620-111 IIT fail bypass Range = 0 to 1 0
620-112 Fan control mode Range = 0 to 1 0
620-113 the number of
APS sensors
Range = 0 to 1 1
620-114 Lamp Fan fal
bypass
Range = 0 to 1 0
620-115 Lamp Fan Low
rotation ON time
Range = 0 to 60 15
620-116 Lamp Fan Off
time
Range = 0 to 60 0
620-117 FL timer set Range = 0 to 1 0
620-118 Lamp On interval Range = 0 to 60 30
620-119 Lamp On time Range = 0 to 60 1
620-120 IIT failure parts
diagnosis
Range = 0 to 65535 0
620-121 Platen SS Regis-
tration Adjust
Platen SS Registration Adjust-
ment
Range = 16 to 184 100
620-122 Platen SS Magni-
fication Adjust
Platen SS Magnification
Adjustment
Range = 44 to 56 50
620-123 Platen glass type Range = 0 to 2 2
620-124 REGI corr value-
FS dir on Platen
REGI correction value in FS
direction on Platen
Range = 0 to 240 120
620-125 CVT FS Off
S1:S1-1 (139.7-
148)
CVT FS Offset Side 1: Side1-1
(139.7 to 148)
Range = 0 to 240 120
620-126 CVT FS Off
S2:S2-1 (139.7-
148)
CVT FS Offset Side 2: Side2-1
(139.7 to 148)
Range = 0 to 240 120
620-127 CVT FS Off
S1:S1-2 (182-
194)
CVT FS Offset Side 1: Side1-2
(182 to 194)
Range = 0 to 240 120
620-128 CVT FS Off
S2:S2-2 (182-
194)
CVT FS Offset Side 2: Side2-2
(182 to 194)
Range = 0 to 240 120
Table 23 CCS NVM ID 620-101 to 620-199
NVM ID NVM Name NVM Description Settings Default
620-129 CVT FS Off
S1:S1-3 (203.2)
CVT FS Offset Side 1: Side1-3
(203.2)
Range = 0 to 240 120
620-130 CVT FS Off
S2:S2-3 (203.2)
CVT FS Offset Side 2: Side2-3
(203.2)
Range = 0 to 240 120
620-131 CVT FS Off
S1:S1-4 (210)
CVT FS Offset Side 1: Side1-4
(210)
Range = 0 to 240 120
620-132 CVT FS Off
S2:S2-4 (210)
CVT FS Offset Side 2: Side2-4
(210)
Range = 0 to 240 120
620-133 CVT FS Off
S1:S1-5 (214.9-
215.9)
CVT FS Offset Side 1: Side1-5
(214.9 to 215.9)
Range = 0 to 240 120
620-134 CVT FS Off
S2:S2-5 (214.9-
215.9)
CVT FS Offset Side 2: Side2-5
(214.9 to 215.9)
Range = 0 to 240 120
620-135 CVT FS Off
S1:S1-6 (254-
257)
CVT FS Offset Side 1: Side1-6
(254 to 257)
Range = 0 to 240 120
620-136 CVT FS Off
S2:S2-6 (254-
257)
CVT FS Offset Side 2: Side2-6
(254 to 257)
Range = 0 to 240 120
620-137 CVT FS Off
S1:S1-7 (266.7-
267)
CVT FS Offset Side 1: Side1-7
(266.7 to 267)
Range = 0 to 240 120
620-138 CVT FS Off
S2:S2-7 (266.7-
267)
CVT FS Offset Side 2: Side2-7
(266.7 to 267)
Range = 0 to 240 120
620-139 CVT FS Off
S1:S1-8 (279.4)
CVT FS Offset Side 1: Side1-8
(279.4)
Range = 0 to 240 120
620-140 CVT FS Off
S2:S2-8 (279.4)
CVT FS Offset Side 2: Side2-8
(279.4)
Range = 0 to 240 120
620-141 CVT FS Off
S1:S1-9 (297)
CVT FS Offset Side 1: Side1-9
(297)
Range = 0 to 240 120
620-142 CVT FS Off
S2:S2-9 (297)
CVT FS Offset Side 2: Side2-9
(297)
Range = 0 to 240 120
620-143 CVT FS Off
S1:S3-1 (139.7-
148)
CVT FS Offset Side 1: Side3-1
(139.7 to 148)
Range = 0 to 240 120
620-144 CVT FS Off
S2:S4-1 (139.7-
148)
CVT FS Offset Side 2: Side4-1
(139.7 to 148)
Range = 0 to 240 120
620-145 CVT FS Off
S1:S3-2 (182-
194)
CVT FS Offset Side 1: Side3-2
(182 to 194)
Range = 0 to 240 120
Table 23 CCS NVM ID 620-101 to 620-199
NVM ID NVM Name NVM Description Settings Default
