Xerox ColorQube 9301

February 2013
6-236
ColorQube® 9303 Family
dC131
General Procedures/Information
620-146 CVT FS Off
S2:S4-2 (182-
194)
CVT FS Offset Side 2: Side4-2
(182 to 194)
Range = 0 to 240 120
620-147 CVT FS Off
S1:S3-3 (203.2)
CVT FS Offset Side 1: Side3-3
(203.2)
Range = 0 to 240 120
620-148 CVT FS Off
S2:S4-3 (203.2)
CVT FS Offset Side 2: Side4-3
(203.2)
Range = 0 to 240 120
620-149 CVT FS Off
S1:S3-4 (210)
CVT FS Offset Side 1: Side3-4
(210)
Range = 0 to 240 120
620-150 CVT FS Off
S2:S4-4 (210)
CVT FS Offset Side 2: Side4-4
(210)
Range = 0 to 240 120
620-151 CVT FS Off
S1:S3-5 (214.9-
215.9)
CVT FS Offset Side 1: Side3-5
(214.9 to 215.9)
Range = 0 to 240 120
620-152 CVT FS Off
S2:S4-5 (214.9-
215.9)
CVT FS Offset Side 2: Side4-5
(214.9 to 215.9)
Range = 0 to 240 120
620-153 CVT FS Off
S1:S3-6 (254-
257)
CVT FS Offset Side 1: Side3-6
(254 to 257)
Range = 0 to 240 120
620-154 CVT FS Off
S2:S4-6 (254-
257)
CVT FS Offset Side 2: Side4-6
(254 to 257)
Range = 0 to 240 120
620-155 CVT FS Off
S1:S3-7 (266.7-
267)
CVT FS Offset Side 1: Side3-7
(266.7 to 267)
Range = 0 to 240 120
620-156 CVT FS Off
S2:S4-7 (266.7-
267)
CVT FS Offset Side 2: Side4-7
(266.7 to 267)
Range = 0 to 240 120
620-157 CVT FS Off
S1:S3-8 (279.4)
CVT FS Offset Side 1: Side3-8
(279.4)
Range = 0 to 240 120
620-158 CVT FS Off
S2:S4-8 (279.4)
CVT FS Offset Side 2: Side4-8
(279.4)
Range = 0 to 240 120
620-159 CVT FS Off
S1:S3-9 (297)
CVT FS Offset Side 1: Side3-9
(297)
Range = 0 to 240 120
620-160 CVT FS Off
S2:S4-9 (297)
CVT FS Offset Side 2: Side4-9
(297)
Range = 0 to 240 120
620-161 W-Ref adjust-
ment factor Red
Range = 70 to 255 140
620-162 W-Ref adjust-
ment factor Green
Range = 70 to 255 140
620-163 W-Ref adjust-
ment factor Blue
Range = 70 to 255 140
620-164 W-Ref adjust-
ment factor BW-X
Range = 70 to 255 140
Table 23 CCS NVM ID 620-101 to 620-199
NVM ID NVM Name NVM Description Settings Default
620-165 W-Ref adjust-
ment factor BW-Y
Range = 70 to 255 140
620-166 W-Ref adj factor
Red (sheet)
W-Ref adjustment factor Red
(each sheet)
Range = 0 to127 63
620-167 W-Ref adj factor
Green (sheet)
W-Ref adjustment factor
Green (each sheet)
Range = 0 to 127 63
620-168 W-Ref adj factor
Blue (sheet)
W-Ref adjustment factor Blue
(each sheet)
Range = 0 to 127 63
620-169 W-Ref adj factor
BW (sheet)
W-Ref adjustment factor BW
(each sheet)
Range = 0 to 127 63
620-170 IIT paper code Range = 0 to 8 0
620-171 Optical axis
adjustment: front
Range = 0 to 1980 990
620-172 Optical axis
adjustment: rear
Range = 0 to 1980 990
620-173 CVT FS Offset
Side 1: Side1
Range = 0 to 240 120
620-174 CVT FS Offset
Side 2: Side2
Range = 0 to 240 120
620-175 CVT FS Offset
Side 1: Side3
Range = 0 to 240 120
620-176 CVT FS Offset
Side 2: Side4
Range = 0 to 240 120
620-177 BW/Color auto
recognition level
Range = 0 to 1 0
620-178 Black line adj
level (for COLOR)
Black line adjustment level (for
COLOR)
Range = 0 to 15 8
620-179 Black line adj
level (for BW)
Black line adjustment level (for
BW)
Range = 0 to 15 8
620-180 Black line adjust-
ment test mode
Range = 0 to 7 0
620-181 BW adjustment
table
Range = 0 to 7 0
620-182 HOSEI_SCAN
(for detection)
Range = 0 to 6 3
620-183 HOSEI_SCAN
(for image)
Range = 0 to 6 3
620-184 CCD Calib Y scan
Red
Range = 0 to 1023 0
620-185 CCD Calib Y
scanned: Green
Range = 0 to 1023 0
620-186 CCD Calib Y
scanned: Blue
Range = 0 to 1023 0
Table 23 CCS NVM ID 620-101 to 620-199
NVM ID NVM Name NVM Description Settings Default
