Xerox ColorQube 9301

February 2013
6-237
ColorQube® 9303 Family
dC131
General Procedures/Information
620-187 CCD Calib M
scanned: Red
Range = 0 to 1023 0
620-188 CCD Calib M
scanned: Green
Range = 0 to 1023 0
620-189 CCD Calib M
scanned: Blue
Range = 0 to 1023 0
620-190 CCD Calib C
scanned: Red
Range = 0 to 1023 0
620-191 CCD Calib C
scanned: Green
Range = 0 to 1023 0
620-192 CCD Calib C
scanned: Blue
Range = 0 to 1023 0
620-193 CCD Calib PK
scanned: Red
Range = 0 to 1023 0
620-194 CCD Calib PK
scanned: Green
Range = 0 to 1023 0
620-195 CCD Calib PK
scanned: Blue
Range = 0 to 1023 0
620-196 Switching A6/
postcard detect
Switching A6 document / post-
card detection
Range = 0 to 2 0
620-197 A4S/8.5in det.
border switch 2
A4S/8.5in detection border
switching 2
Range = 0 to 6 3
620-198 B5/8W10 detec-
tion switch
Range = 0 to 3 0
620-199 Switch 8.5W13/
8.5W14 detec
-
tions
Range = 0 to 3 0
Table 24 CCS NVM ID 620-200 to 620-299
NVM ID NVM Name NVM Description Settings Default
620-200 Select special-
doc-detect table
Select special-document-
detection table
Range = 0 to 2 0
620-201 Switch docu size
detect tables
Switch document size detec-
tion tables
Range = 1 to 5 2
620-202 Switch A3/11W17
detections
Range = 0 to 3 0
620-203 Switch A4/
8.5W11 detec
-
tions
Range = 0 to 3 0
620-204 Document size
detection.
Range = 0 to 1 0
620-205 GCO/TFX sizes
switching
Range = 0 to 1 1
Table 23 CCS NVM ID 620-101 to 620-199
NVM ID NVM Name NVM Description Settings Default
620-206 B4/8-kai FS
threshold setting
Range = 0 to 6 3
620-207 8-kai/11W17SEF
FS threshold
8-kai/11W17SEF FS threshold
setting
Range = 0 to 6 3
620-208 Switch B6/5W7
detections
Range = 0 to 2 0
620-209 Lamp check NG
counts
Range = 0 to 65535 0
620-210 Data taken at
lamp check NG.
Range = 0 to 1023 0
620-211 AOC flow endings
with error
the number of AOC flow end-
ings with error
Range = 0 to 255 0
620-212 BW Copy BGR-
AE adjustment
level
Range = 0 to 4095 0
620-213 Color copy BGR-
AE adjust level
Color copy BGR-AE adjust-
ment level
Range = 0 to 4095 0
620-214 TP_BW_Copy
BGR-AE-Level
Speed
BW Copy BGR-AE adjustment
- speed-prioritized
Range = 0 to 4095 0
620-215 TX_CL_Copy
BGR-AE-Level
Speed
Color copy BGR-AE adjust-
ment - speed-prioritized AE
(Text)
Range = 0 to 4095 0
620-216 TP_BW_Contone
BGR-AE-Level
Speed
BW contone scan BGR-AE
adjustment level for speed-pri
-
oritized AE (Text photo)
Range = 0 to 4095 0
620-217 TP_CL_Contone
BGR-AE-Level
Speed
Color contone scan BGR-AE
adjustment level for speed-pri
-
oritized AE (Text photo)
Range = 0 to 4095 0
620-218 ABS; FS non-
detected area 1
background suppression; FS
non-detected area 1
Range = 0 to 65535 255
620-219 ABS; FS non-
detected area 2
background suppression; FS
non-detected area 2
Range = 0 to 65535 255
620-220 ABS; FS non-
detected area 3
background suppression; FS
non-detected area 3
Range = 0 to 65535 255
620-221 ABS; FS non-
detected area 4
background suppression; FS
non-detected area 4
Range = 0 to 65535 255
620-222 ABS; SS fixed
position
background suppression; SS
fixed position
Range = 0 to 65535 60
620-223 ABS; SS end
position (for HAE)
background suppression; SS
end position (for HAE)
Range = 0 to 65535 240
620-224 ABS; SS end
position (for MAE)
background suppression; SS
end position (for MAE)
Range = 0 to 65535 240
620-225 ABS; SS end
position (for NAE)
background suppression; SS
end position (for NAE)
Range = 0 to 65535 240
Table 24 CCS NVM ID 620-200 to 620-299
NVM ID NVM Name NVM Description Settings Default
