Xerox ColorQube 9301 Service Manual

February 2013
6-241
ColorQube® 9303 Family
dC131
General Procedures/Information
620-359 SS MAX value Range = 1297 to
4418
2100
620-360 SS MIN value Range = 1297 to
4418
2100
620-361 Document Size Range = 3 to 20 8
620-362 Specify docu-
ment feed direc-
tion
Range = 0 to 1 0
620-363 DADF Doc Size
Detection Table
Select DADH document size
detection table custom regis
-
tration
Range = 0 to 1 0
620-364 S Size Side2
Lead Regi Adjust
S-size document Side2 Lead
Regi correction value
Range = 217 to 283 250
620-365 M Size Side2
Lead Regi Adjust
M-size document Side2 Lead
Regi correction value
Range = 217 to 283 250
620-366 L Size Side2
Lead Regi Adjust
L-size document Side2 Lead
Regi correction value
Range = 217 to 283 250
620-367 Size Mismatch
Set(Simp)
Size mismatch Jam detection
setting (applicable to only Sim
-
plex Mode)
Range = 1 to 2 1
620-368 Alternate Size
switching 1
Range = 1 to 2 1
620-369 Alternate Size
switching 2
Range = 1 to 2 1
620-370 Alternate Size
switching 3
Range = 0 to 2 0
620-371 Alternate Size
switching 4
Range = 0 to 2 0
620-372 Alternate Size
switching 5
Range = 0 to 2 0
620-373 Alternate Size
switching 6
Range = 0 to 3 0
620-374 Alternate Size
switching 7
Range = 0 to 3 0
620-375 Alternate Size
switching 8
Range = 0 to 4 0
620-376 Alternate Size
switching 9
Range = 0 to 2 0
620-377 Alternate Size
switching 10
Range = 0 to 2 0
620-378 Alternate Size
switching 11
Range = 0 to 3 0
620-379 Size-Mix Mode
Assumed Size
Size-Mix Mode temporary size
direction
Range = 0 to 1 1
Table 25 CCS NVM ID 620-300 to 620-399
NVM ID NVM Name NVM Description Settings Default
620-380 Fax job Mix Size
Standard mode
Range = 0 to 1 0
620-381 DADF DPM
selection
Range = 0 to 65535 80
620-382 Magnification cor-
rection control
Range = 0 to 1 0
620-383 Color BW judg-
ment level
Range = 0 to 4 2
620-384 textmode Photo/
Text RecogLvl
YATAGRS text mode Photo
and Text Recognition level
Range = 0 to 4 2
620-385 BW copy (text
photo) AE adj lvl
BW copy (text photo) AE
adjustment level
Range = 0 to 4095 0
620-386 CL copy (text
photo) AE adj lvl
Color copy (text photo) AE
adjustment level
Range = 0 to 4095 0
620-387 BW Copy text AE
adjustment level
BW Copy (text) AE adjust-
ment level
Range = 0 to 4095 0
620-388 CL Copy (text) AE
adj lvl
Color Copy (text) AE adjust-
ment level
Range = 0 to 4095 0
620-389 BW CopyFor B
AE adjust level
BW Copy for B AE adjustment
level
Range = 0 to 4095 0
620-390 BW Copy G and
R AE adj lvl
BW Copy for G and R AE
adjustment level
Range = 0 to 4095 0
620-391 CL Copy B AE adj
lvl
Color Copy for B AE adjust-
ment level
Range = 0 to 4095 0
620-392 CL Copy G and R
AE adj lvl
Color Copy for G and R AE
adjustment level
Range = 0 to 4095 0
620-393 BW Copy (text) B
AE adj lvl
BW Copy (text) for B AE
adjustment level
Range = 0 to 4095 0
620-394 BW Copy (text) G
& R AE adj lvl
BW Copy (text) for G and R AE
adjustment level
Range = 0 to 4095 0
620-395 CL Copy (text) B
AE adj lvl
Color Copy (text) for B AE
adjustment level
Range = 0 to 4095 0
620-396 CL Copy (text) G
& R AE adj lvl
Color Copy (text) for G and R
AE adjustment level
Range = 0 to 4095 0
620-397 EXT. Tail Reg. adj
(55.0 mm/sec)
EXT. Tail Reg. adjustment
(55.0 mm/sec)
Range = 0 to 244 122
620-398 EXT. Tail Reg. adj
(73.3 mm/sec)
EXT. Tail Reg. adjustment
(73.3 mm/sec)
Range = 0 to 244 122
620-399 EXT. Tail Reg. adj
(82.5 mm/sec)
EXT. Tail Reg. adjustment
(82.5 mm/sec)
Range = 0 to 244 122
Table 25 CCS NVM ID 620-300 to 620-399
NVM ID NVM Name NVM Description Settings Default
