Xerox ColorQube 9301 Service Manual

February 2013
6-240
ColorQube® 9303 Family
dC131
General Procedures/Information
620-301 Hue angle M end Range = 0 to 360 360
620-302 Hue angle C start Range = 0 to 360 190
620-303 Hue angle C end Range = 0 to 360 280
620-304 IISS-DADF com-
munication Fail
Range = 0 to 65535 0
620-305 Not displayed IISS-DADH communication
Fail
Range = 0 to 65535 0
620-306 IISS-Controller
comm Fai
IISS-Controller communica-
tion Fail
Range = 0 to 65535 0
620-307 Not displayed IISS-Controller communica-
tion Fail
Range = 0 to 65535 0
620-308 DADF EEPROM
Fail
Range = 0 to 65535 0
620-309 Not displayed DADH EEPROM Fail Range = 0 to 65535 0
620-310 IPS Fan Fail Range = 0 to 65535 0
620-311 Not displayed IPS Fan Fail Range = 0 to 65535 0
620-312 CRG Position Fail Range = 0 to 65535 0
620-313 Not displayed CRG Position Fail Range = 0 to 65535 0
620-314 IISS LOGIC Fail Range = 0 to 65535 0
620-315 Not displayed IISS LOGIC Fail Range = 0 to 65535 0
620-316 Lamp Illumina-
tion Fail
Range = 0 to 65535 0
620-317 Not displayed Lamp Illumination Fail Range = 0 to 65535 0
620-318 CRG Over Run
Fail
Range = 0 to 65535 0
620-319 Not displayed CRG Over Run Fail Range = 0 to 65535 0
620-320 Lamp Fan Fail Range = 0 to 65535 0
620-321 Not displayed Lamp Fan Fail Range = 0 to 65535 0
620-322 CCD Fan Fail Range = 0 to 65535 0
620-323 Not displayed CCD Fan Fail Range = 0 to 65535 0
620-324 AGC Fail Range = 0 to 65535 0
620-325 Not displayed AGC Fail Range = 0 to 65535 0
620-326 AOC Fail Range = 0 to 65535 0
620-327 Not displayed AOC Fail Range = 0 to 65535 0
620-328 IPS PWBA Fail Range = 0 to 65535 0
620-329 Not displayed IPS PWBA Fail Range = 0 to 65535 0
620-330 IISS-EXT com-
munication Fail
Range = 0 to 65535 0
620-331 Not displayed IISS-EXT communication Fail Range = 0 to 65535 0
620-332 Extension
EEPROM Fail
Range = 0 to 65535 0
620-333 Not displayed Extension EEPROM Fail Range = 0 to 65535 0
Table 25 CCS NVM ID 620-300 to 620-399
NVM ID NVM Name NVM Description Settings Default
620-334 IPS-EXT Connec-
tion Fail
Range = 0 to65535 0
620-335 Not displayed IPS-EXT Connection Fail Range = 0 to 65535 0
620-336 IPS-YATA Con-
nection Fail
Range = 0 to 65535 0
620-337 Not displayed IPS-YATA Connection Fail Range = 0 to 65535 0
620-338 EXT-YATA Con-
nection Fail
Range = 0 to 65535 0
620-339 Not displayed EXT-YATA Connection Fail Range = 0 to 65535 0
620-340 YATA PWBA Fail Range = 0 to 65535 0
620-341 Not displayed YATA PWBA Fail Range = 0 to 65535 0
620-342 IPS PWBA Mem-
ory Fail
Range = 0 to 65535 0
620-343 Not displayed IPS PWBA Memory Fail Range = 0 to 65535 0
620-344 IIT Hot Line Fail Range = 0 to 65535 0
620-345 Not displayed IIT Hot Line Fail Range = 0 to 65535 0
620-346 Scan Count
replace life
(upper)
Scan Count replacement life
(upper)
Range = 0 to 65535 91
620-347 Scan Count
replace life
(lower)
Scan Count replacement life
(lower)
Range = 0 to 65535 36224
620-348 Lamp-On time
replace life (max)
Lamp-On time Count replace-
ment life (upper)
Range = 0 to 65535 109
620-349 Lamp-On time
replace life (min)
Lamp-On time Count replace-
ment life (lower)
Range = 0 to 65535 56576
620-350 Lamp-On Count
replace life (max)
Lamp-On Count Replacement
life (upper)
Range = 0 to 65535 91
620-351 Lamp-On Count
replace life (min)
Lamp-On Count Replacement
life (lower)
Range = 0 to 65535 36224
620-352 Fax doc Size
detect DADF
Fax Document Size Detection
for DADH
Range = 0 to 1 0
620-353 JAM bypass Range = 0 to 1 0
620-354 8.5 W11 LEF
threshold
Range = 1993 to
2193
2093
620-355 B5SEF / 8 W10
SEF switching
Range = 0 to 1 0
620-356 11x15 SEF/8-kai
switch (AP Mkt)
11 W15 SEF / 8-kai switching
in AP market
Range = 0 to 1 0
620-357 FS MAX value Range = 1297 to
3070
2970
620-358 FS MIN value Range = 1297 to
3070
2970
Table 25 CCS NVM ID 620-300 to 620-399
NVM ID NVM Name NVM Description Settings Default
