February 2013
6-245
ColorQube® 9303 Family
dC131
General Procedures/Information
620-516 Black Scanned
Lifetime Docs
Not displayed
Black Scanned Lifetime Docu-
mentsNumber of jobs (not
impressions) since activation
that were scanned while Black
Mode is selected
Range = 0 to
16777215
0
620-517 Color Scanned
Lifetime Docs
Not displayed
Color Scanned Lifetime Docu-
mentsNumber of jobs (not
impressions) since activation
that were scanned while Color
Mode is selected
Range = 0 to
16777215
0
620-518 Greyscale
Scanned Lifetime
Docs
Not displayed
Greyscale Scanned Lifetime
DocumentsNumber of jobs
(not impressions) since activa
-
tion that were scanned while
Greyscale Mode is selected
Range = 0 to
16777215
0
620-519 Text Scanned
Lifetime Docs
Not displayed
Text Scanned Lifetime Docu-
mentsNumber of jobs (not
impressions) since activation
that were scanned while Text
Mode is selected
Range = 0 to
16777215
0
620-520 Photo Scanned
Lifetime Docs
Not displayed
Photo Scanned Lifetime Docu-
mentsNumber of jobs (not
impressions) since activation
that were scanned while Photo
Mode is selected
Range = 0 to
16777215
0
620-521 Mixed Scanned
Lifetime Docs
Not displayed
Mixed Scanned Lifetime Docu-
mentsNumber of jobs (not
impressions) since activation
that were scanned while Mixed
Mode is selected
Range = 0 to
16777215
0
620-522 DADH OpenDur-
ingRunFC
05-300 Fault Counter: DADH
open during run
Range = 0 to 255 0
620-523 DADHLHCovInt-
lockOpenDurin-
gRunFC
05-307 Fault Counter: DADH
LH cover interlock opened dur
-
ing run
Range = 0 to 255 0
620-524 DADH Source
Doc Too Short FC
05-310 Fault Counter: DADH
Source Doc Too Short For
DADH
Range = 0 to 255 0
620-525 LE late to post
feed sensorS5 FC
05-330 Fault Counter: LE late
to post feed sensor S5 (mis
-
feed)
Range = 0 to 255 0
620-526 TE late to post
feed sensorS5 FC
05-331Fault Counter: TE late
to post feed sensor S5 (multi
-
feed)
Range = 0 to 255 0
620-527 LE late to TAR
sensor S6 FC
05-335 Fault Counter: LE late
to TAR sensor S6
Range = 0 to 255 0
Table 27 CCS NVM ID 620-500 to 620-560
NVM ID NVM Name NVM Description Settings Default
620-528 LE late to Reg.
Sensor S7 FC
05-340 Fault Counter: LE late
to Reg. Sensor S7
Range = 0 to 255 0
620-529 LE late to Exit
sensor S8 FC
05-345 Fault Counter: LE late
to Exit sensor S8 (FWD)
Range = 0 to 255 0
620-530 TE late to Exit
sensor S8 FC
05-346 Fault Counter: TE late
to Exit sensor S8 (FWD)
Range = 0 to 255 0
620-531 LE late to CVT
sensor S10 FWD
FC
05-350 Fault Counter: LE late
to CVT sensor S10 (FWD)
Range = 0 to 255 0
620-532 LE late to CVT
sensor S10 REV
FC
05-352 Fault Counter: LE late
to CVT sensor S10 (REV)
Range = 0 to 255 0
620-533 IIT comm faults IIT comm faults: Used to count
a collection of IIT Comms
faults that may occur.(e.g. not
just linked to one single fault)
Range = 0 to
4294967295
0
620-535 Tot. Scanner
Jams since power
on
Total number of Scanner Jams
since activation.
Range = 0 to 65535 0
620-548 KernelCheck-
SumErrorFC
Fault Counter 05-250-00: Ker-
nel Checksum Error
Range = 0 to 255 0
620-549 Applica-
tionCheckSumEr-
rorFC
Fault Counter 05-251-00:
Application checksum error
Range = 0 to 255 0
620-550 StepperControl-
lerCommsEr-
rorFC
Fault Counter 05-252-00:
Stepper Controller Comms
Error
Range = 0 to 255 0
620-551 IIT-DADHcom-
msErrorFC
Fault Counter 05-253-00: IIT-
DADH Comms Error
Range = 0 to 255 0
620-552 CommsSequen-
ceErrorFC
Fault Counter 05-254-00:
Comms Sequence Error
Range = 0 to 255 0
620-553 DADHhotlineEr-
rorFC
Fault Counter 05-259-00:
DADH Hotline Error
Range = 0 to 255 0
620-554 DADHnotInStand-
byFC
Fault Counter 05-260-00:
DADH not in standby
Range = 0 to 255 0
620-556 Num of jobs
scanned at
150
x 150
150 x 150 Scanned Lifetime
DocumentsNumber of jobs
(not impressions) since activa
-
tion that were scanned where
the user selected
150 x 150
resolution
Range = 0 to
4294967295
0
Table 27 CCS NVM ID 620-500 to 620-560
NVM ID NVM Name NVM Description Settings Default
