February 2013
6-271
ColorQube® 9303 Family
dC330
General Procedures/Information
12-233 Ejector Roll Motor Runs the HVF ejector roll motor
(MOT12-235)
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 90 seconds
time out
12-234 Ejector Motor Home Runs the LCSS ejector motor
(MOT12-236) to the home position
On/off. 5 seconds
time out
12-235 Ejector Motor Move Runs the LCSS ejector motor
(MOT12-237) to the out position
On/off. 5 seconds
time out
12-236 Ejector Motor Cycle Runs the LCSS and HVF ejector motor
(MOT12-238) cycle routine until time
out or stop.
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 90 seconds
time out
12-237 Paddle Roll Motor
Home
Runs the LCSS paddle roll motor
(MOT12-239) to the home position
On/off. 15 seconds
time out
12-238 Paddle Roll Motor Run Runs the LCSS and HVF paddle roll
motor (MOT12-240) until timeout or
stop
On/off. 15 seconds
time out
12-239 Paddle Unit Motor
Descend
Runs the HVF lower paddle unit motor
(MOT12-241) in reverse.
On/off. 90 seconds
time out
12-240 Paddle Unit Motor Lift Runs the HVF paddle unit motor
(MOT12-242) to lift the paddle unit
On/off. 90seconds
timeout
12-241 Bin 1 Elevator Motor
Home
Runs the LCSS and HVF bin 1 elevate
motor (MOT12-241) to the home posi
-
tion.
On/off. 15 seconds
time out
12-242 Bin1 Elevator Motor
Cycle
Runs the LCSS and HVF bin 1 elevate
motor (MOT12-242) to cycle bins up/
down until time-out or stop.
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 90 seconds
time out.
12-243 Punch Head Move
Home
Runs the LCSS hole punch motor
(MOT12-243) to the home position
On/off. 15 seconds
time out
Table 20 Output codes 12
Code Displayed Name Description General
12-244 Punch Head Run Runs the LCSS and HVF hole punch
motor (MOT12-244) continuously
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 15 seconds
time out
12-245 Punch Unit Motor For-
ward
Runs the HVF punch unit motor
(MOT12-245) forward
On/off.
12-246 Punch Unit Motor
Reverse
Runs the HVF punch unit motor
(MOT12-245) in reverse
On/off.
12-247 Staple Head 1 Motor Runs the LCSS and HVF staple head
1 motor (MOT12-247)
CAUTION
Do not run code 12-247 without 2
sheets of paper in the stapler jaws.
Running this code without the paper in
position can cause damage to the
machine.
On/off. 15 seconds
time out
12-248 SH 1 Motor Reverse
Home
Runs the LCSS and HVF staple head
1 motor (MOT12-248) in reverse to the
home position
On/off. 15 seconds
time out
12-249 SU 1 Motor Forward Runs the LCSS and HVF stapling unit
1 motor (MOT12-249) increment for
-
ward.
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 15 seconds
time out
12-250 SU1 Motor Cycle Runs the LCSS and HVF stapling unit
1 motor (MOT12-250) cycle routine
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 90 seconds
time out
12-251 BM Compiler Motor Runs the HVF BM compiler motor
(MOT12-251)
On/off. 90 seconds
time out
12-252 BM Crease Blade
Motor
Runs the HVF BM crease blade motor
(MOT12-252) cycle routine
On/off. 90 seconds
time out
12-253 BM Crease Roll Motor Runs the HVF BM crease roll motor
(MOT12-253)
On/off. 6 seconds
timeout
Table 20 Output codes 12
Code Displayed Name Description General
