Xerox ColorQube 9301 Service Manual

February 2013
6-270
ColorQube® 9303 Family
dC330
General Procedures/Information
Output Codes
Table 17 Input codes 94
Code Displayed Name Description General
94-105 Cleaning unit home
sensor
IME cleaning unit home sensor High/low
Table 18 Output codes 05
Code Displayed Name Description General
05-062 DADH feed clutch DADH feed clutch (CL05-062) On/off. Normally linked with
feed motor. 30 seconds time
-
out.
05-074 DADH feed motor DADH feed motor (MOT05-074) On/off. 90 seconds timeout
05-098 DADH nudger
motor
DADH nudger motor (MOT05-098) On/off. 10 seconds time out
05-099 DADH CVT motor DADH CVT stepper motor
(MOT05-099)
On/off. 90 seconds timeout
05-100 DADH duplex
solenoid
DADH duplex/exit solenoid
(SOL05-101)
On/off. 90 seconds timeout
05-101 DADH Active Hot-
line
DADH Active Hotline. Required to
keep alive until DADH Hotline
Detect sensor can be run.
High = Active. 90 seconds
time out
Table 19 Output codes 10
Code Displayed Name Description General
10-018 Post Transfix
motor (M4)
Post transfix motor M4 (MOT10-
018)
On/off.
10-019 Front Transfix
Motor
Front Transfix Motor (MOT10-019) On/off.
10-020 Rear Transfix
Motor
Rear Transfix Motor (MOT10-020) On/off.
10-021 Stripper Solenoid Stripper Solenoid (SOL10-021) On/off.
10-022 Stripper Jam
Clearance LED
Stripper Jam Clearance LED On/off.
10-023 Strip Gate Latch Strip Gate Latch On/off.
10-024 Transfix Front and
Back
Transfix Front and Back On/off.
10-025 Strip Gate Unlatch Strip Gate Unlatch On/off.
Table 20 Output codes 12
Code Displayed Name Description General
12-045 SU1 motor backward HVF/LCSS Staple unit 1 motor reverse
(MOT12-045)
CAUTION
Do not run the following codes
together: 12-045, 12-233, 12-236, 12-
242, 12-244, 12-249, 12-250. Run
-
ning these codes at the same time can
cause damage to the machine.
On/off. 110 millisec-
onds time out.
12-056 SetCamp SolenoidOn HVF SetClamp SolenoidOn (SOL12-
056)
On/off. 100 millisec-
onds time out.
12-059 Elevator motor up HVF/LCSS Elevator motor up On/off.
500miliseconds tim
-
eout.
12-060 Elevator motor down HVF/LCSS Elevator motor down On/off.
500miliseconds tim
-
eout.
12-223 Transport Motor 1 Runs the LCSS transport Motor 1, and
HVF transport motor 1A and Transport
motor 1B (MOT12-223)
On/off. 90 seconds
time out
12-224 Transport Motor 2 Runs the LCSS, and HVF transport
motor 2 (MOT12-224)
On/off. 90 seconds
time out
12-225 Exit Diverter Solenoid Runs the LCSS, HVF exit diverter gate
solenoid and HVF BM upper diverter
solenoid (SOL12-225)
On/off. 5 seconds
time out
12-226 Front Tamper Motor
Home
Runs the LCSS and HVF front tamper
motor (MOT12-227) to the home posi
-
tion.
On/off. 5 seconds
time-out
12-227 Rear Tamper Motor
Home
Runs the LCSS and HVF rear tamper
motor (MOT12-228) to home position
On/off. 5 seconds
time out
12-228 Front Tamper Motor
Move
Runs the LCSS and HVF front tamper
motor (MOT12-226) move inbound.
On/off. 5 seconds
time out
12-229 Rear Tamper Motor
Move
Runs the LCSS and HVF rear tamper
motor (MOT12-227) move inbound.
On/off. 5 seconds
time out
12-230 Tampers to A4LEF Moves the LCSS tampers to A4LEF
position.
On/off. 5 seconds
time out
12-231 Tampers to 8.5x11LEF Move the LCSS tampers to 8.5”x11”
LEF position.
On/off. 5 seconds
time out
12-232 Tamper Motor Cycle Cycles the LCSS tampers in and out
until time-out or stop.
On/off. 90 seconds
time out
