Xerox ColorQube 9301 Service Manual

February 2013
6-269
ColorQube® 9303 Family
dC330
General Procedures/Information
74-413 Bypass nudger home
sensor
Bypass nudger home sensor (Q74-
413)
On/off
74-415 Bypass width pot value Returns actual width size based on
width sensor state (Q74-415)
Value between 0 and
3.65
Table 11 Input codes 75
Code Displayed Name Description General
75-010 Tray 5 door switch Detects presence of tray 5 door in
closed position / toggle switch up
position
High = door closed =
toggle switch up
75-011 Tray 5 stack height
sensor
Detects paper stack is in correct
position to feed from tray 5
High = stack up
75-012 Tray 5 down sensor Detects when tray 5 is lowered High = paper tray low-
ered
75-016 Tray 5 empty sensor Detects when the tray is empty High = tray empty
75-017 Tray 5 docking switch Detects when the tray is docked
against the machine
High = tray docked
Table 12 Input codes 82
Code Displayed Name Description General
82-110 Vertical transport sen-
sor (5)
IME vertical transport sensor (5) High/low
82-125 Confirm sensor (16) IME confirm sensor (16) High/low
Table 13 Input codes 83
Code Displayed Name Description General
83-010 Duplex sensor (17) Duplex sensor (17) High/Low
83-110 Duplex start sensor
(13)
IME duplex start sensor (13) High/low
83-125 Duplex end sensor
(14)
IME duplex end sensor (14) High/low
Table 14 Input codes 89
Code Displayed Name Description General
89-004 Reg / Preheat Home
sensor
IME RLPH reg / preheat home sen-
sor
High/low
89-005 Registration scan bar IME registration scan bar On/off
89-006 Pretransfix sensor (20) IME pretransfix sensor (20) High/low
Table 10 Input codes 74
Code Displayed Name Description General
Table 15 Input codes 91
Code Displayed Name Description General
91-011 Lower carriage home
sensor
IME lower carriage home sensor High/low
91-012 Upper carriage home
sensor
IME upper carriage home sensor High/low
91-014 HM Position Sensor IME HM position sensor High/low
91-019 Waste tray sensor IME waste tray sensor High/low
Table 16 Input codes 93
Code Displayed Name Description General
93-025 Ink load door switch IME ink load door switch High/low
93-026 Ink load entry snr
Magenta 1
IME Ink load entry sensor Magenta
1
High/low
93-027 Ink load entry snr Cyan
2
IME Ink load entry sensor Cyan 2 High/low
93-028 Ink load entry snr Yel-
low 3
IME Ink load entry sensor Yellow 3 High/low
93-029 Ink load entry snr
Black 4
IME Ink load entry sensor Black 4 High/low
93-030 Ink load low snr
Magenta 1
IME Ink load low sensor Magenta 1 High/low
93-031 Ink load low snr Cyan
2
IME Ink load low sensor Cyan 2 High/low
93-032 Ink load low snr Yel-
low 3
IME Ink load low sensor Yellow 3 High/low
93-033 Ink load low snr Black
4
IME Ink load low sensor Black 4 High/low
93-034 Ink load sensor Black
1
IME Ink load sensor K1 High/low
93-035 Ink load sensor
Magenta 1
IME Ink load sensor M1 High/low
93-036 Ink load sensor Cyan 1 IME Ink load sensor C1 High/low
93-037 Ink load sensor Yellow
1
IME Ink load sensor Y1 High/low
93-038 Ink load sensor Black
2
IME Ink load sensor K2 High/low
93-039 Ink load sensor
Magenta 2
IME Ink load sensor M2 High/low
93-040 Ink load sensor Cyan 2 IME Ink load sensor C2 High/low
93-041 Ink load sensor Yellow
2
IME Ink load sensor Y2 High/low
