February 2013
6-268
ColorQube® 9303 Family
dC330
General Procedures/Information
Table 5 Input codes 62
Code Displayed Name Description General
62-018 Carriage Home Sensor Scan carriage home sensor (Q62-
018) detects the home position of
the scan carriage
High = Home, low = not
home
62-019 Platen down sensor Scanner platen down sensor (Q62-
019) detects DADH is closed.
High = closed, low =
open
62-020 24v detect Detects 24v in scanner High = +24v present,
low = +24v not present
62-021 12v detect Detects 12v in scanner High = +12v present,
low = +12v not present
62-022 DADH hotline detect DADH active hotline detection sen-
sor
High = Hotline active
Low = Hotline inactive
62-251 Document size sensor
1
Document size sensor 1(Q62-251)
located under the platen glass
High = paper present
62-253 Document size sensor
2
Document size sensor 2(Q62-253)
located under the platen glass
High = paper present
62-301 Angle sensor Scanner angle sensor (Q62-301) High/Low
Table 6 Input codes 70
Code Displayed Name Description General
70-100 Horz transport home
switch
3TM. Detects presence of horizon-
tal transport in home position
High/low
70-101 Vert transport home
sensor
3TM. Detects presence of vertical
transport in home position.
High/low
70-398 Tray 3 transport sen-
sor
3TM. Detects presence of sheet in
horizontal position
High = paper present
Table 7 Input codes 71
Code Displayed Name Description General
71-101 T1 Feed Sensor 3TM. Detects when lead edge of
paper at Tray 1 feed sensor (Q71-
101)
High = paper present
71-201 Tray 1 Empty Sensor 3TM. To detect Tray 1 empty sen-
sor on (Q71-201). Not used for
SAR feeders.
High/low
71-311 T1 Size Switch 1 Size switch 1 (S71-311) High = made
71-312 T1 Size Switch 2 Size switch 2 (S71-312) High = made
71-313 T1 Size Switch 3 Size switch 3 (S71-313) High = made
71-314 T1 Size Switch 4 Size switch 4 (S71-314) High = made
71-315 T1 Size Switch 5 Size switch 5 (S71-314) High = made
71-336 T1 Stack Height Sen-
sor
3TM. Detects paper stack is in cor-
rect position to feed from tray 1
(Q71-336)
High = stack up
71-395 TAR 1 sensor 3TM. Detects presence of paper at
TAR 1 sensor (Q71-395)
High = made
Table 8 Input codes 72
Code Displayed Name Description General
72-102 T2 feed sensor 3TM. Detects when lead edge of
paper at tray 2 feed sensor (Q72-
101)
High = paper present
72-201 Tray 2 empty sensor 3TM. To detect tray 2 empty sensor
on (Q72-201). Not used for SAR
feeders.
High/low
72-321 T2 Size Switch 1 Size switch 1 (S72-321) High = made
72-322 T2 Size Switch 2 Size switch 2 (S72-322) High = made
72-323 T2 Size Switch 3 Size switch 3 (S72-323) High = made
72-324 T2 Size Switch 4 Size switch 4 (S72-324) High = made
72-325 T2 Size Switch 5 Size switch 5 (Q72325), Not used
for SAR feeders
High = made
72-337 T2 Stack Height Sen-
sor
3TM. Detects paper stack is in cor-
rect position to feed from T2 (Q72-
337)
High = stack up
72-396 TAR 2 sensor 3TM. Detects presence of paper
sheet at TAR 2 sensor (Q72-396)
High = made
Table 9 Input codes 73
Code Displayed Name Description General
73-103 T3 feed sensor Detects when lead edge of paper at
tray 3 feed sensor
High = paper present
73-201 T3 empty sensor To detect tray 3 empty sensor on High/low
73-303 T3 home sensor Detects when tray 3 home High/low
73-383 T3 stack height sensor Tray 3 elevated to feed position High/low
73-397 TAR 3 sensor Detects presence of paper sheet at
TAR 3 sensor
High/low
Table 10 Input codes 74
Code Displayed Name Description General
74-335 Bypass empty sensor Bypass paper empty sensor (Q74-
335)
High = paper present
74-350 Bypass width sensor Bypass analogue width sensor
(Q74-350)
Voltage range (for p1)
width (in mm/inch post
p1)
74-406 Bypass feed sensor Detects the lead edge of paper at
bypass feed sensor
High = paper present
