February 2013
6-267
ColorQube® 9303 Family
dC330
General Procedures/Information
12-195 Punch hd present sen-
sor
LCSS punch head present sensor
(Q12-195) detects if a hole punch is
installed
High = punch installed,
low = punch not
installed
12-196 SH1 paper sensor LCSS staple head 1 home sensor
(Q12-196) detects when the staple
head is fully open (home position)
High = home, low = not
home
12-197 Top cover interlock Detects if finisher top cover is open High = closed
12-202 Ejector paper present
sensor
HVF ejector paper present sensor
(Q12-202) detects compiled paper
for stapling
On = made
12-204 BM guide home sensor HVF BM backstop guide home sen-
sor (Q12-204) detects when the
backstop is in the home position
High = home, low = not
home
12-205 BM tamper 1 home
sensor
HVF BM tamper 1 home sensor
(Q12-205) detects when the BM
tampers are in the home position
High = home, low = not
home
12-206 BM Bin2 90% full sen-
sor
HVF BM bin 2 90% full sensor
(Q12-206) detects when bin 2 is
90% or more full
High = 90% or more full,
low = less than 90% full
12-207 Flapper home sensor HVF booklet maker flapper home
sensor (Q12-207)
High = home
12-208 PTU switch HVF PTU switch (S12-208) detects
if pause to unload button is pressed
High = made, low = not
detected
12-209 TriFold front dr inter-
lock
HVF tri fold door interlock (S12-
209) detects if the tri fold front door
is closed
High = closed, low =
door open
12-210 TriFold top cover inter-
lock
HVF tri fold top cover interlock
(S12-210) detects if the tri fold top
cover is closed
High = closed, low =
cover open
12-211 OCT 90% Full sensor OCT level sensor (Q12-211)
detects when the tray is 90% full
High = 90% full
12-212 OCT index sensor OCT index sensor (Q12-212)
detects when a tray is in an index
position
High = at index position
12-213 BM exit sensor HVF BM exit sensor (Q12-213)
detects booklets exiting the booklet
maker
High = detected, low =
not detected
12-214 BM crease blade home HVF BM crease blade home sensor
(Q12-214) detects when the crease
blade is fully retracted
High = home, low = not
home
12-215 BM crease blade
motor encoder
HVF BM crease blade motor
encoder (Q12-215) generates
motor speed pulses
High = bar in encoder
wheel, low = gap in
encoder wheel
Table 4 Input codes 12
Code Displayed Name Description General
12-216 BM crease roll motor
encoder
HVF BM crease roll motor encoder
sensor (Q12-216) generates motor
speed pulses
High = bar in encoder
wheel, low = gap in
encoder wheel
12-217 BM SH carrier closed HVF BM staple head carrier closed
sensor (Q12-217) detects when the
carrier is in the closed position
High = closed, low = not
closed
12-218 BM SH1 home sensor HVF BM staple head 1 home sen-
sor (Q12-218) detects when the
staple head is fully open (home
position)
High = home, low = not
home
12-219 BM SH1 staples low HVF BM staple head 1 staples low
sensor (Q12-219) detects when
staple cartridge is almost empty
High = almost empty,
low = plentiful staples
12-220 BM SH2 home sensor HVF BM staple head 2 home sen-
sor (Q12-220) detects when the
staple head is fully open (home
position)
High = home, low = not
home
12-221 BM SH2 staples low HVF BM staple head 2 staples low
sensor (Q12-221) detects when
staple cartridge is almost empty
High = almost empty,
low = plentiful staples
12-222 BM crease roll gate
home
HVF BM crease roll gate home
sensor (Q12-222) detects when the
gate is fully raised (home position)
High = gate raised, low
= gate not raised
12-303 Front door interlock LCSS and HVF front door interlock
(Q12-303) detects if the finisher
front door is open
High = closed, low =
open
12-315 Inserter pickup sensor Inserter pickup sensor (Q12-315)
detects trail edge of paper
On = made
12-316 Inserter acceleration
sensor
Inserter acceleration sensor (Q12-
316) detects acceleration position
of paper
On = made
12-317 Stapler cartridge sen-
sor
HVF Stapler cartridge sensor On = made
Off = clear
12-318 Stapler jaw home sen-
sor
HVF/LCSS Stapler jaw home sen-
sor
On = made
Off = clear
12-319 Stapler safety switch HVF Stapler safety switch On = made
Off = clear
12-320 Inserter standby sen-
sor
Inserter standby sensor On = made
Off = clear
12-321 Buffer path sensor HVF Buffer path sensor On = made
Off = clear
12-322 Paper pressing sensor HVF Paper pressing sensor On = made
Off = clear
Table 4 Input codes 12
Code Displayed Name Description General
