ColorQube® 9303 Family
PJ Locations
Wiring Data
PJ Locations
PJ Location Tables
To locate a PJ, go to the appropriate table.
• PJ1 to PJ99, Table 1.
• PJ100 to PJ149, Table 2.
• PJ150 to PJ199, Table 3.
• PJ200 to PJ299, Table 4.
• PJ300 to PJ399, Table 5.
• PJ400 to PJ449, Table 6.
• PJ450 to PJ499, Table 7.
• PJ500 to PJ549, Table 8.
• PJ550 to PJ599, Table 9.
• PJ600 to PJ899, Table 10.
• PJ900 to PJ999, Table 11.
• PJDC1 to PJDC4, Table 12.
Location Figures for PWB Connectors and In-line Connectors
NOTE: Part list references are given with each figure.
1. 3 tray module PWB, Figure 9.
2. BM PWB, Figure 25.
3. DADH PWB, Figure 4.
4. Drum driver PWB, Figure 12.
5. Fax connector PWB, Figure 7.
6. Foreign device interface PWB, Figure 28
7. HVF PWB, Figure 21.
8. IME Controller PWB, Figure 14.
9. Ink load entry PWB, Figure 19.
10. Inserter PWB, Figure 24.
11. IOD pre amplifier PWB, Figure 13.
12. In-line connector PJ140 and in-line PJ, Figure 30.
13. In-line connector PJ530, Figure 22.
14. In-line connectors PJ704, PJ851, PJ904, Figure 6.
15. LCSS PWB, Figure 26.
16. Marking unit driver PWB, Figure 16.
17. Marking unit heater PWB, Figure 15.
18. Media path driver PWB, Figure 10.
19. Offline staple PWB (LCSS), Figure 27.
20. Power Supply Unit, Figure 1.
21. Power Distribution PWB, Figure 2.
22. Printhead, Figure 20.
23. Quad wave amplifier PWB, Figure 17.
24. Registration / preheat Interface PWB, Figure 11.
25. Scanner PWB, Figure 5.
26. Single board controller PWB, Figure 29.
27. Solenoid patch PWB, Figure 18.
28. Tray 5 control PWB, Figure 8.
29. Tri folder PWB, Figure 23.
30. UI PWB’s, Figure 3.
Table 1 PJ1 to PJ99
PJ number PJ location figure PJ location
Wiring
diagram
1 Figure 2 Power Distribution PWB WD 1.6
1 Figure 11 Registration / Preheat Interface PWB WD 8.6
1 Figure 13 IOD pre amplifier board PWB WD 9.1
1 Figure 24 Inserter PWB WD 12.21
1 Figure 29 Single board controller PWB N/A
1 Figure 7 Fax connector PWB WD 3.1
2 Figure 2 Power Distribution PWB WD 1.6
2 Figure 11 Registration / Preheat Interface PWB WD 8.6
2 Figure 13 IOD pre amplifier board PWB WD 9.1
2 Figure 24 Inserter PWB WD 12.21
2 Figure 7 Fax connector PWB WD 3.1
3 Figure 2 Power Distribution PWB WD 1.7
3 Figure 11 Registration / Preheat Interface PWB WD 8.6
3 Figure 24 Inserter PWB WD 12.21
4AC Figure 1 Power Supply Unit WD 1.1
4 Figure 11 Registration / Preheat Interface PWB WD 8.6
4 Figure 24 Inserter PWB
WD 12.21, WD
12.22
5AC Figure 1 Power Supply Unit WD 1.2
5 Figure 11 Registration / Preheat Interface PWB WD 8.6
5 Figure 24 Inserter WD 12.21
5 Figure 29 Single board controller PWB WD 3.1
6AC Figure 1 Power Supply Unit WD 1.1
6 Figure 24 Inserter PWB WD 12.21
7 Figure 24 Inserter PWB WD 12.21
8AC Figure 1 Power Supply Unit WD 1.1
8 Figure 2 Power Distribution PWB WD 1.7
8 Figure 24 Inserter PWB
WD 12.21, WD
12.22
9 Figure 2 Power Distribution PWB WD 1.7
9 Figure 24 Inserter PWB WD 12.22
