Xerox ColorQube 9301 Service Manual

February 2013
7-4
ColorQube® 9303 Family
PJ Locations
Wiring Data
10 Figure 24 Inserter PWB WD 12.22
10 Figure 29 Single board controller PWB WD 3.1
11 Figure 24 Inserter PWB WD 12.22
11 Figure 29 Single board controller PWB N/A
12 Figure 24 Inserter PWB WD 12.22
12 Figure 29 Single board controller PWB N/A
13 Figure 24 Inserter PWB WD 12.22
13 Figure 29 Single board controller PWB WD 3.1
15 Figure 29 Single board controller PWB WD 3.1
16 Figure 28 Foreign Device Interface PWB WD 3.3
16 Figure 29 Single board controller PWB WD 3.2
17 Figure 29 Single board controller PWB WD 3.2
18 Figure 29 Single board controller PWB WD 3.2
19 Figure 29 Single board controller PWB WD 3.2
20 Figure 29 Single board controller PWB WD 3.3
21 Figure 29 Single board controller PWB N/A
24 Figure 29 Single board controller PWB WD 3.3
25 Figure 29 Single board controller PWB WD 3.3
45 Figure 29 Single board controller PWB WD 3.3
49 Figure 29 Single board controller PWB WD 3.1
Table 2 PJ100 to PJ149
PJ number PJ location figure PJ location Wiring diagram
100 Figure 28 Foreign Device Interface PWB WD 3.3
101 Figure 20 Printhead 1 PWB WD 9.20
101 Figure 20 Printhead 2 PWB WD 9.20
101 Figure 20 Printhead 3 PWB WD 9.21
101 Figure 20 Printhead 4 PWB WD 9.21
101 Figure 12 Drum Driver PWB WD 9.1
101 Figure 10 Media path driver PWB WD 8.2
101 Figure 15 Marking unit heater board PWB WD 9.8
101 Figure 16 Marking unit driver PWB WD 9.9
101 Figure 21 HVF PWB WD 12.7
102 Figure 16 Marking unit driver PWB WD 9.9
102 Figure 21 HVF PWB WD 12.7, WD
12.8
103 Figure 21 HVF PWB WD 12.8
104 Figure 10 Media path driver PWB WD 8.1
Table 1 PJ1 to PJ99
PJ number PJ location figure PJ location
Wiring
diagram
104 Figure 21 HVF PWB WD 12.8
105 Figure 14 IME controller PWB WD 9.5
110 Figure 17 Quad wave amplifier PWB WD 9.13
110 Figure 18 Solenoid patch PWB WD 9.14
111 Figure 21 HVF PWB WD 12.8
112 Figure 21 HVF PWB WD 12.6, WD
12.8
113 Figure 21 HVF PWB WD 12.6, WD
12.8
121 Figure 21 HVF PWB WD 12.9
130 Figure 18 Solenoid patch PWB WD 9.14
131 Figure 21 HVF PWB WD 12.6, WD
12.9
132 Figure 21 HVF PWB WD 12.6, WD
12.9
133 Figure 21 HVF PWB WD 12.9
140 Figure 30 In line connector (on the rear frame) WD 1.2
Table 3 PJ150 to PJ199
PJ number PJ location figure PJ location Wiring diagram
150 Figure 17 Quad wave amplifier PWB WD 9.13
181 Figure 4 DADH PWB WD 5.1
183 Figure 4 DADH PWB WD 5.1
184 Figure 4 DADH PWB WD 5.1
186 Figure 4 DADH PWB WD 5.1
187 Figure 4 DADH PWB WD 5.1
188 Figure 4 DADH PWB WD 5.2
189 Figure 4 DADH PWB WD 5.2
190 Figure 4 DADH PWB WD 5.2
Table 4 PJ200 to PJ299
PJ number PJ location figure PJ location Wiring diagram
201 Figure 14 IME Controller PWB WD 9.5
201 Figure 15 Marking unit heater PWB WD 9.8
201 Figure 19 Ink load entry PWB WD 9.17
202 Figure 10 Media path driver PWB
Refer to in-line PJ connector at Figure
30
WD 8.1
Table 2 PJ100 to PJ149
PJ number PJ location figure PJ location Wiring diagram
