February 2013
7-5
ColorQube® 9303 Family
PJ Locations
Wiring Data
202 Figure 21 HVF PWB WD 12.9, WD
12.10
203 Figure 16 Marking unit driver PWB WD 9.10
206 Figure 10 Media path driver PWB WD 8.2
210 no link Hard Disc Drive WD 3.3
211 no link Hard Disc Drive WD 3.3
222 Figure 29 Single board controller PWB WD 3.3
223 Figure 29 Single board controller PWB WD 3.2
Table 5 PJ300 to PJ399
PJ number PJ location figure PJ location Wiring diagram
300 Figure 26 LCSS PWB WD 12.1
301 Figure 20 Printhead 1 PWB WD 9.20
301 Figure 20 Printhead 2 PWB WD 9.20
301 Figure 20 Printhead 3 PWB WD 9.21
301 Figure 20 Printhead 4 PWB WD 9.21
301 Figure 14 IME Controller PWB WD 9.5
301 Figure 19 Ink load entry PWB WD 9.17
301 Figure 21 HVF PWB WD 12.10
301 Figure 26 LCSS PWB WD 12.1
302 Figure 21 HVF PWB WD 12.11
302 Figure 26 LCSS PWB WD 12.1
303 Figure 10 Media path driver PWB
Refer to in-line PJ connector located on
the rear frame above A4 jam clearance
guide
WD 8.1, WD 8.2
303 Figure 16 Marking unit driver PWB WD 9.10, WD
9.11
303 Figure 21 HVF PWB WD 12.11
303 Figure 26 LCSS PWB WD 12.1
304 Figure 16 Marking unit driver PWB WD 9.11
304 Figure 21 HVF PWB WD 12.11
304 Figure 26 LCSS PWB WD 12.1
305 Figure 26 LCSS PWB WD 12.1
306 Figure 26 LCSS PWB WD 12.2
307 Figure 26 LCSS PWB WD 12.2
308 Figure 26 LCSS PWB WD 12.2, WD
12.3
309 Figure 26 LCSS PWB WD 12.3
310 Figure 26 LCSS PWB WD 12.3
Table 4 PJ200 to PJ299
PJ number PJ location figure PJ location Wiring diagram
311 Figure 26 LCSS PWB WD 12.3
312 Figure 26 LCSS PWB WD 12.3, WD
12.4
313 Figure 26 LCSS PWB WD 12.4
314 Figure 26 LCSS PWB WD 12.4
315 Figure 26 LCSS PWB WD 12.4
316 Figure 26 LCSS PWB WD 12.5
317 Figure 26 LCSS PWB WD 12.5
318 Figure 26 LCSS PWB WD 12.5
350 Figure 27 LCSS Pause to unload PWB WD 12.4
380 Figure 18 Solenoid patch PWB WD 9.16
Table 6 PJ400 to PJ449
PJ number PJ location figure PJ location Wiring diagram
401 Figure 12 Drum Driver PWB WD 9.1
401 Figure 10 Media path driver PWB WD 8.2
401 Figure 21 HVF PWB WD 12.11, WD
12.12
401 Figure 14 IME Controller PWB WD 9.5
401 Figure 15 Marking unit heater PWB WD 9.8
401 Figure 16 MU driver PWB WD 9.11
402 Figure 10 Media path driver PWB WD 8.2
402 Figure 14 IME Controller PWB WD 9.5
402 Figure 21 HVF PWB WD 12.12
403 Figure 14 IME Controller PWB WD 9.6
403 Figure 21 HVF PWB WD 12.12
405 Figure 10 Media path driver PWB WD 8.3
406 Figure 10 Media path driver PWB WD 8.4
408 Figure 10 Media path driver PWB WD 8.4
410 Figure 18 Solenoid patch PWB WD 9.15
430 Figure 18 Solenoid patch PWB WD 9.14
Table 7 PJ450 to PJ499
PJ number PJ location figure PJ location Wiring diagram
495 no link OCT PWB WD 12.23
496 PJ at component OCT 90% full sensor WD 12.23
497 PJ at component OCT index sensor WD 12.23
Table 5 PJ300 to PJ399
PJ number PJ location figure PJ location Wiring diagram
