February 2013
7-11
ColorQube® 9303 Family
PJ Locations
Wiring Data
In-line Connectors PJ704, PJ851, PJ904
Location: PL 75.68, PL 5.10 Item 6, PL 12.00 (OCT), PL 12.75 (LCSS), PL 12.140 (HVF),
Figure 6 PJ704, PJ851, PJ904
Fax Connector PWB
Location: PL 20.05 Item 2
Figure 7 Fax connector PWB
PJ704
PJ904
PJ851
PJ2
PJ1
