Status Indicator RAPs
YN
Go to 01H and follow the procedure for the media path driver PWB.
Refer to WD 1.5. Disconnect PJDC4 from the power supply unit and check for a short circuit
between pins 17 to chassis and from pin 18 to the chassis with the PJDC4 disconnected.
The
circuit is good.
YN
Go to 01H and follow the procedure for the power distribution PWB.
No short has been found in the +24V circuits, refer to the fault history for an insight into the
fault area, then go to 01H and check that area.
+12V Short Circuit Check
Procedure
Switch off the machine, GP 14.
Refer to WD 1.4. Disconnect PJDC1 from the power supply unit and check for a short circuit
between pin 13 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01E and follow the procedure for the IME controller PWB.
Go to 01E and follow the procedure for the Quad wave amp PWB.
Refer to WD 1.5. Disconnect PJDC3 from the power supply unit and check for a short circuit
between pin 17 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01E and follow the procedure for the drum driver PWB.
With PJDC3 still disconnected from the power supply unit, check for a short circuit between pin
22 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01E and follow the procedure for the media path driver PWB.
Refer to WD 1.5. Disconnect PJDC4 from the power supply unit and check for a short circuit
between pin 14 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01E and follow the procedure for the power distribution PWB.
No short has been found in the +12V circuits, refer to the fault history for an insight into the
fault area, then go to 01E and check that area.
-12V Short Circuit Check
Procedure
Switch off the machine, GP 14.
Refer to WD 1.4. Disconnect PJDC1 from the power supply unit and check for a short circuit
between pin 12 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01F and follow the procedure for the IME controller PWB.
Go to 01F and follow the procedure for the Quad wave amp PWB.
Refer to WD 1.5. Disconnect PJDC3 from the power supply unit and check for a short circuit
between pin 16 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01F and follow the procedure for the drum driver PWB.
With PJDC3 still disconnected from the power supply unit, check for a short circuit between pin
23 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01F and follow the procedure for the media path driver PWB.
No short has been found in the -12V circuits, refer to the fault history for an insight into the fault
area, then go to 01F and check that area.
+5V Short Circuit Check
Procedure
Switch off the machine, GP 14.
Refer to WD 1.4. Disconnect PJDC1 from the power supply unit and check for a short circuit
between pin 17 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01D and follow the procedure for the IME controller PWB.
Go to 01D and follow the procedure for the Quad wave amp PWB.
Refer to WD 1.5. Disconnect PJDC3 from the power supply unit and check for a short circuit
between pin 19 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01D and follow the procedure for the drum driver PWB.
With PJDC3 still disconnected from the power supply unit, check for a short circuit between pin
20 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01D and follow the procedure for the media path driver PWB.
Refer to WD 1.5. Disconnect PJDC4 from the power supply unit and check for a short circuit
between pin 13 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01D and follow the procedure for the power distribution PWB.
With PJDC4 still disconnected from the power supply unit, check for a short circuit between pin
11 of the disconnected PJ and the chassis.
The circuit is good.
YN
Go to 01E and follow the procedure for the HDD.
The fault is still active.
YN
Perform SCP 5 Final Actions.
Install a new power supply unit, PL 1.15 Item 2.
