Xerox ColorQube 9301

February 2013
2-574
ColorQube® 9303 Family
OF 4b
Status Indicator RAPs
- 91-841-00 IME in jet substitution and
single sided print mode.
Increments the AIF
counter by 2
No service action required.
- 92-802-00 PEST soft faults are
raised
Review dC123 PEST fault his-
tory log
- 92-820-00 PEST warnings exist -
- 93-877-00 Magenta sold ink stick
expected, DMO was
detected
Incompatible black ink
detected. Refer to GP 34.
Notify the system administrator.
All machine services are avail
-
able
- 93-878-00 This status is raised when
the detected ink stick is
different from the
expected one (as per the
billing type)
Incompatible magenta ink
detected. Refer to GP 34.
Notify the system administrator.
All machine services are avail
-
able
- 93-879-00 This status is raised when
the detected ink stick is
different from the
expected one (as per the
billing type)
Incompatible cyan ink
detected. Refer to GP 34.
Notify the system administrator.
All machine services are avail
-
able
- 93-880-00 This status is raised when
the detected ink stick is
different from the
expected one (as per the
billing type)
Incompatible yellow ink
detected. Refer to GP 34.
Notify the system administrator.
All machine services are avail
-
able
- 93-881-00 This status is raised when
the detected ink stick is
different from the
expected one (as per the
billing type)
Incompatible black ink
detected. Refer to GP 34.
Notify the system administrator.
All machine services are avail
-
able.
- 93-905-00 It is raised when the IME
recognizes that the cyan
ink stick is consumed.
This means it went past
the ink low flag (it's past
the point it can be
removed from the sys
-
tem and will be con-
sumed). This is critical for
supplies replenishment
and is used to estimate
the rate at which ink
sticks are being used
No service action required. All
services are available
Table 1 Status messages - to F
UI Message
Status
Code Reason for Message Reference / Action
- 93-906-00 It is raised when the IME
recognizes that the
magenta ink stick is con
-
sumed. This means it
went past the ink low flag
(it's past the point it can
be removed from the sys
-
tem and will be con-
sumed). This is critical for
supplies replenishment
and is used to estimate
the rate at which ink
sticks are being used
No service action required. All
services are available
- 93-907-00 It is raised when the IME
recognizes that the yel
-
low ink stick is consumed.
This means it went past
the ink low flag (it's past
the point it can be
removed from the sys
-
tem and will be con-
sumed). This is critical for
supplies replenishment
and is used to estimate
the rate at which ink
sticks are being used
No service action required. All
services are available
- 93-908-00 It is raised when the IME
recognizes that the black
ink stick is consumed.
This means it went past
the ink low flag (it's past
the point it can be
removed from the sys
-
tem and will be con-
sumed). This is critical for
supplies replenishment
and is used to estimate
the rate at which ink
sticks are being used
No service action required. All
services are available
- 93-941-00 Magenta sold ink stick
expected, DMO was
detected
Incompatible magenta ink
detected. Refer to GP 34.
Notify the system administrator.
All machine services are avail
-
able
Table 1 Status messages - to F
UI Message
Status
Code Reason for Message Reference / Action
