February 2013
2-591
ColorQube® 9303 Family
OF 4b
Status Indicator RAPs
Paper jam in the
finisher
12-624-00 A sheet is over the
inserter pickup sensor
Clear the area. If the problem per-
sists, perform the 12-479-00-171
RAP
Paper jam in the
finisher
12-625-00 A sheet is over the
inserter tab standby
sensor
Clear the area. If the problem per-
sists, perform the 12-191-00-171,
12-193-00-171, 12-194-00-171, 12-
196-00-171 RAP
Paper jam in the
finisher
12-626-00 A sheet is over the
buffer position sensor
Clear the area. If the problem per-
sists, perform the 12-198-00-171,
12-199-00-171 RAP
Paper jam in the
finisher
12-627-00 A sheet is over the
HVF exit into BM sen
-
sor
Clear the area. If the problem per-
sists, perform the 12-198-00-171,
12-199-00-171 RAP
Paper jam in the
finisher
12-628-00 A sheet is over the
stacker bin exit sensor
Clear the area. If the problem per-
sists, perform the 12-151-171, 12-
152-171
Paper jam in the
finisher
12-629-00 A sheet is over the tri-
folder entry sensor
Clear the area. If the problem per-
sists, perform the 12-183-00-171,
12-184-00-171 RAP
Paper jam in the
finisher
12-630-01 A sheet is over the
booklet maker entry
sensor (without tri-
folder)
Clear the area. If the problem per-
sists, perform the 12-183-00-171,
12-184-00-171 RAP
Paper jam in the
finisher
12-630-02 A sheet is over the
booklet maker entry
sensor (with tri-folder)
Clear the area. If the problem per-
sists, perform the 12-183-00-171,
12-184-00-171 RAP
Paper jam in the
finisher
12-636-01 A sheet is over the
booklet maker exit
sensor. (without tri-
folder)
Clear the jam from the output bin. If
the problem persists, perform the 12-
181-00-171, 12-182-00-171 RAP
Paper jam in the
finisher
12-636-02 A sheet is over the
booklet maker exit
sensor. (with tri-folder)
Clear the jam from the output bin. If
the problem persists, perform the 12-
181-00-171, 12-182-00-171 RAP
Paper jam in the
finisher.
12-732-00 A sheet is detected
near the PPI pickup
sensor
Clear the jam. If necessary, perform
the 12-191-00-171, 12-193-00-171,
12-194-00-171, 12-196-00-171 RAP
Paper jam in the
finisher.
12-733-00 A sheet is detected
near the PPI tab
standby sensor
Clear the jam. If necessary, perform
the 12-191-00-171, 12-193-00-171,
12-194-00-171, 12-196-00-171 RAP
Paper jam in the
finisher.
12-627-01 A page is over exit
HVF into BM sensor
(sensor in area 6a)
cleared via area 6a
Clear the paper jam
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
Paper jam in the
finisher.
12-627-02 A page is over exit
HVF into BM sensor
(sensor in area 6a)
Cleared via area 6a
Clear the paper jam
Paper jam in the
finisher.
12-746-00 A sheet is detected
near the tri-fold entry
sensor
Clear the sheet. If the problem per-
sists, perform the 12-183-00-171,
12-184-00-171 RAP
Paper jam in the
finisher.
12-747-00 A sheet is detected
near the tri-fold exit
sensor
Clear the sheet. If the problem per-
sists, perform the 12-185-00-171 to
12-187-00-171
Paper jam in the
finisher.
12-748-00 A sheet is detected
near the tri-fold assist
sensor
Clear the sheet. If the problem per-
sists, perform the 12-185-00-171 to
12-187-00-171 RAP
Paper jam in the
finisher.
12-717-01 A sheet is over HVF
BM compiler paper
present sensor (with
-
out tri-folder)
Clear the HFV BM paper present
sensor area 6e. If the problem per
-
sists, perform the 12-166-00-171
RAP
Paper jam in the
finisher.
12-717-02 A sheet is over HVF
BM compiler paper
present sensor (with
tri-folder)
Clear the HFV BM paper present
sensor area 6e. If the problem per
-
sists, perform the 12-166-00-171
RAP
Paper required for
current job is not
available
22-511-04 The media required
for the current mark
-
ing job is not loaded
Load the correct paper to complete
the held job or cancel the held job.
Other machine services are unaf
-
fected
Paper tray commu-
nication fault.
Please call for
assistance.
92-531-00 3TM Communica-
tions problems (Ttm-
SerialLinkSafety)
Switch the machine off then on, GP
14. Check connection on 3 trays
module. If problem persists, perform
the 70-312-00 Tray 1 to Tray 3 Com
-
munication Failure RAP. Copying
and printing are not available.
Paper tray commu-
nication fault.
Please call for
assistance.
92-530-00 IME communications
problem with paper
tray. Paper trays 1 to
3 not available.
Switch the machine off then on, GP
14. Check connection on 3 trays
module. If problem persists, perform
the 70-312-00 Tray 1 to Tray 3 Com
-
munication Failure RAP. Copying
and printing are not available.
Please complete
all steps required
by the external
accounting device
to access this ser
-
vice
03-558-00 Not defined -
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
