Xerox ColorQube 9301 Service Manual

February 2013
2-620
ColorQube® 9303 Family
OF 16
Status Indicator RAPs
The sequence loops continuously so each set of blinks does not need to be read consec-
utively.
2. After the flutter count the number of blinks to determine the hundreds digit. At the end of
the first digit there will be a pause.
3. After the pause count the number of blinks to determine the tens digit. At the end of the
second digit there will be a second pause.
4. After the second pause count the number of blinks to determine the ones digit.
5. Refer to Table 1 for a list of POST blink codes and definitions.
• IME POST CPU errors are blink codes 2XX.
• IME POST Communication errors are blink codes 3XX.
• IME POST Engine errors are blink codes 4XX.
6. Check the wiring and all connectors on the relevant PWB as indicated by the error code.
Perform the service actions shown in Table 1.
NOTE: After completing the service actions to clear the fault the print engine should boot
up normally, but then display a fault code relating to the fault just cleared. Switch off, then
switch on the machine, GP 14 to clear the fault code.
7. If the fault remains or no blink codes are communicated, go to Additional LED Checks.
Table 1 POST Hard Fault Codes
Error Code Service action
POST_BAD_ERROR_CODE 211 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_PROG_MACHINE_CHECK 212 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_PROG_SYS_PANIC 213 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_ ECM_FPGA_LOAD_FAILURE 215 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_ECM_FPGA_MAPPING_FAILURE 216 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_ECM_FPGA_ID_READ_FAILURE 217 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_ECM_FPGA_ID_MISMATCH 218 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_FPGA_WRITE_MISMATCH 219 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_IMAGE_FPGA_LOAD_FAILURE 223 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_IMAGE_FPGA_MAPPING_FAILURE 224 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_IMAGE_FPGA_ID_READ_FAILURE 225 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_IMAGE_FPGA_ID_MISMATCH 226 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_IMAGE_FPGA_WRITE_MISMATCH 227 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
POST_NVRAM_ACCESS_FAILURE 231 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
ENG_SC_CONNECT_FAULT 321 Perform the following:
1. Check (RJ45 connector) PJ16 on
the single board controller PWB.
2. Check between (RJ45 connector)
PJ16 and PJ401 on the IME con
-
troller PWB.
3. Check for +5V supply to the single
board controller PWB, refer to the
01D +5V Distribution RAP.
4. Check the condition of the LEDs
on the single board controller
PWB, refer to the OF 5 Boot Up
Failure RAP. Perform any relevant
service actions.
5. If the fault remains, perform an Alt-
boot, GP 4.
ENG_TEST4 411 This code is not for field use.
ENG_PWR_NO_HEATER_REQ 412 Install a new IME controller PWB, PL
92.10 Item 1.
ENG_SAFETY_TIMEOUT_LNK 413 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
ENG_SYS_TIMER 414 This code is not for field use.
ENG_PCI_ACCESS_ERROR 415 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
ENG_ADC_FAILED 416 Switch off, then switch on the machine,
GP 14. If the fault remains, install a new
IME controller PWB, PL 92.10 Item 1.
Table 1 POST Hard Fault Codes
Error Code Service action
