Chapter 3 PERFORMING MEASUREMENTS
3-91
Switching the Drive to Another
This section explains how to switch the drive.
♦ Example: “INTERNAL MEMORY” → “PCMCIA”
If no drives are installed on the instrument or if they are installed but not connected,
it is not possible to select them. In this case, the measured data will be saved to the
internal memory. The floppy disk drive cannot be selected unless a floppy disk is
inserted into the floppy disk drive.
1. Locate the cursor to “DRIVE” by using the arrow key.
The cursor is already located at “DRIVE” when the file operation window is
displayed.
2. Press [ENTER].
A selection window will appear.
*: Indicates the default setting.
3. Locate the cursor to “PCMCIA” by using the rotary knob or [S] / [T].
4. Press [ENTER] to register the change made to the drive setting.
TIP
EXTENSION UNIT
USB
PCMCIA
Selectable drives
*INTERNAL MEMORY
Caution
TIP
To Next Page
