Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-44
Device Message
No. Function
Header
Numeric
Part
Description
11-1 Trace type TRC m Sets the trace display method.
m= 0: Dot
1: Line
11-2 Cursor type
Second cursor
CSR m Sets the cursor display method.
m= 0: “+” (Second cursor OFF)
1: “|” (Second cursor OFF)
2: “+” (Second cursor ON)
3: “|” (Second cursor ON)
11-3 Grid show/hide setting GD m Shows/hides the grid.
m= 0: Hides the grid.
1: Shows the grid.
11-4 Trace display DOT m Sets the trace display dot method.
m= 0: Decimation
1: Mean
2: Maximum
3: Envelope
11-5 Distance unit DM m Sets the distance unit.
m= 0: km
1: mile
2: kf
This setting is effective for all the distance related
items.
11-6 Distance reference marker DUO m Sets the type of the distance origin marker.
m= 0: Line
1: Arrow
11-7 dB digit FIG m Sets the number of display digits for intensity level.
m= 0: ∗∗.∗∗∗
1: ∗∗.∗∗
2: ∗∗.∗
11-8 Display color DIS m Sets the display color.
m= 0: Color 1
1: Color 2
2: Color 3
3: B&W
11-9 Date display format DTE m Sets the date display format.
m= 0: Not displayed
1: APR. 30. 2004
2: 30. APR. 2004
3: 2004. APR. 30
4: 4. 30. 2004
5: 30. 4. 2004
6: 2004. 4. 30
11-10 Year correction YEA m Corrects the year (4-digit).
1970 ≤ m ≤ 2037:1step
11-11 Month correction MTH m Corrects the month.
01 ≤ m ≤ 12:1step
11-12 Day correction DAY m Corrects the day.
m=01 to 31:1step
11-13 Hour correction HOU m Corrects the hour.
m=00 to 23:1step
11-14 Minute correction MIN m Corrects the minute.
m=00 to 59:1step
To Next Page
