YOKOGAWA AQ7260 OTDR User Manual

Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-45
Device Message
No. Function
Header
Numeric
Part
Description
11-15 Alarm sound setting BEEP m Enables/disables the alarm.
m= 0: Disables the alarm.
1: Enables the alarm.
11-16 Power save setting POW m Sets the power save function.
m= 0: OFF
1: 30sec
2: 1min
3: 3min
4: 5min
5: 10min
6: 20min
11-17 LCD brightness setting BRI m Sets the LCD brightness.
m= 0: Bright
1: Normal
2: Dark
11-18 PCMCIA cancel PCME Shuts off the power to the PCMCIA card.
11-19 Print direction setting PRD m Sets the print direction.
m= 0: Horizontal
1: Vertical
2: Screen
11-20 Print color setting PRIC m Sets the print color.
m= 0: Display
1: B&W
This setting is effective only if “USB” is set by
command 13-1.
12-1 Printer setting PRO m Sets the printer port.
m= 0: Expansion unit
1: -
2: -
3: -
4: -
5: USB(HP)
6: USB(EPSON)
12-2 Printer status check No control command
12-3 RS-232C setting No control command
13-1 Trace data quantity No control command
13-2
Trace data (ASCII)
No control command
13-3
Trace data (binary)
No control command
13-4
Displayed trace data
(ASCII)
No control command
13-5
Displayed trace data
(binary)
No control command
13-6
Acquisition of file size
No control command
13-7
Acquisition of file
No control command
