YOKOGAWA PX8000 User Manual

French
ATTENTION
• Ne pas toucher la tête d’impression. Vous pourriez vous brûler.
• Ne pas toucher la section du coupe-papier à l’extrémité du cache de l’imprimante. Vous
pourriez vous blesser.
Raise the
handle.
Printer cover
OPEN COVER
button
Press the OPEN COVER button to
open the printer cover.
Set the roll paper in the
orientation shown in
the figure.
Roll paper cutter section
Print head
Align the ends of the roll paper with
the guides and set the roll in place.
Close the printer cover and
press LOCK at the center of
the cover until you hear a click.
Guide
4.
5.
1. 2.
3.
21.1 Loading Roll Paper Into the Built-In Printer (Optional)
21-2
IM PX8000-02EN
