7-1
IM PX8000-02EN
Chapter 7 Numeric Computation
7.1 Turning Numeric Measurement On and Off
This section explains how to turn numeric measurement on and off.
► Features Guide: “Turning Numeric Measurement On and Off (Numeric Measure)”
NUMERIC Menu
Press NUMERIC to display the following menu.
Turns numeric measurement on and off
To measure voltage, current, power, and other measurement functions, set this to ON.
If this is set to OFF, none of the measurement functions will be measured, and every
numeric data will be displayed as no data (−−−−−−−).
Note
If every numeric data (see chapter 6) is displayed as no data (−−−−−−−) even when you turn numeric
measurement on, check the following items.
• Is waveform acquisition running? ► section 4.2
• Is the trigger set properly?
Trigger mode ► section 3.1
Trigger position and trigger delay ► section 3.2
Trigger hold off ► section 3.3
Trigger conditions according to trigger type ► sections 3.4 to 3.15
To Next Page
