YOKOGAWA PX8000 User Manual

18-1
IM PX8000-02EN
18.1 Setting Actions
This section explains the following settings for executing the action function.
• Action mode
• Action
► Features Guide: “Action”
ACTION Menu
Press SHIFT+MODE (ACTION) to display the following menu.
Set Mode to ON.
Set the actions.
Setting Actions (Action Setup)
Press the Action Setup soft key to display the following screen.
Select the actions to execute (Beep, Print Image, Save Waveform,
Save Numeric, Save Image).
Set the waveform data save
destination.
► section 22.3
Set this when Save Waveform is
selected for the action.
Set the screen capture save
destination.
► section 22.3
Set this when Save Image is
selected for the action.
Set the numeric data save
destination.
► section 22.3
Set this when Save Numeric is
selected for the action.
Chapter 18 Action
