24-3
IM PX8000-02EN
24.3 Setting Time Synchronization (Option)
This section explains the following settings for synchronizing the PX8000 to GPS time.
• IRIG format
• Modulation type
• Input impedance
► Features Guide: “Time Synchronization Feature (Time Synchro; optional)”
UTILITY System Config Time Synchro Menu
Press UTILITY, the System Config soft key, and then the Time Synchro soft key to display the
following menu.
Set the modulation type (AM, PWCode).
Set the IRIG format (A, B).
Set the time synchronization feature (OFF, IRIG).
Set the input impedance (50, 5k).
Note
To enable the changes that you have made to the time synchronization settings, restart the PX8000.
To Next Page
