YOKOGAWA PX8000 User Manual

8-3
IM PX8000-02EN
8.2 Using the Snapshot and Clear Trace Features
This section explains how to use the snapshot feature (which retains the currently displayed
waveforms on the screen) and the clear trace feature (which clears all displayed waveforms).
► Features Guide: “Snapshot (SNAPSHOT)”
“Clear Trace (CLEAR TRACE)”
Snapshot (SNAPSHOT)
Press SNAPSHOT to retain the currently displayed waveform on the screen as a snapshot waveform
in white. Snapshot waveforms remain on the screen until you execute a clear trace operation.
Clear Trace (CLEAR TRACE)
Press CLEAR TRACE to clear all the waveforms that are displayed on the screen.
Note
Click SHIFT+SNAPSHOT to clear only the snapshot waveforms.
