25-10

IM PX8000-02EN

SD Card Test

Set the test type to SD Card.

Starts testing

Printer Test

Set the test type to Printer.

Starts testing

If an Error Occurs during a Self-Test

If an error occurs even after you carry out the following procedure, contact your nearest YOKOGAWA

dealer.

• Execute the self-test again several times.

• Confirm whether or not the media being tested is properly inserted.

• Check that the paper is set properly in the built-in printer and that paper is not jammed.

25.2 Carrying Out Self-Tests (Selftest)
