Setting the Reference Mode (Mode)
Set what kind of relationship must be established between period T and the specified reference
times (Time or T1 and T2) for the PX8000 to trigger.
T < Time Period T must be shorter than the reference time (Time).
T > Time Period T must be longer than the reference time (Time).
T1 < T < T2 Period T must be longer than reference time T1 and shorter than reference time T2.
T < T1, T2 <T Period T must be shorter than reference time T1 or longer than reference time T2.
3.12 Triggering on a Period Trigger (Enhanced)
